| Ref | Part Number | Description |
|---|
| 5 |
ROPE |
Ref: 6 0325431 *SPRING, Starter 0325431 |
| 27 |
0328333 |
SCREW |
| 28 |
0326129 |
SLEEVE |
| 29 |
0326130 |
GROMMET |
| 31 |
0328731 |
VIS, câble de verrouillage |
| 34 |
0330276 |
LOCKOUT LEVER |
| 35 |
0326128 |
SPRING |
| 36 |
0328456 |
CLAMP |
| 37 |
0342818 |
PULLEY, Start |
| 38 |
0336135 |
SCREW, Flywheel |
| 39 |
0326249 |
HANDLE, Starter |
| 42 |
0437040 |
LOCKOUT LEVER Assy |
| 44 |
0438753 |
BRACKET & SPACER, Starter handle |
| 45 |
0343600 |
WASHER, Screw, pulley |
| 46 |
0342819 |
COLLAR |
| 47 |
0335220 |
SCREW, Bracket |
| 48 |
0319415 |
SCREW |
| 53 |
0438233 |
CABLE ASSY., Lockout |
| 54 |
0330338 |
SLIDE |
| 55 |
0586331 |
STOP SWITCH ASSY. |
| 0438104 |
0438104 |
RECOIL STARTER Assy |
