| Ref | Part Number | Description |
|---|
| 10 |
278001307 |
WIRE SEAL - Call your local BRP dealership |
| 17 |
278000996 |
WIRE SEAL - Call your local BRP dealership |
| 32 |
278000998 |
Female Terminal |
| 33 |
278000999 |
Wire Seal |
| 75 |
409010700 |
Female Terminal |
| 77 |
409010300 |
Female Terminal |
| 79 |
710000038 |
Female Terminal |
| 83 |
561503100 |
FEMALE TERMINAL - Call your local BRP dealership |
| 85 |
710000036 |
Female Terminal |
| 86 |
278000995 |
FEMALE TERMINAL - Call your local BRP dealership |
| 87 |
278000994 |
FEMALE TERMINAL - Call your local BRP dealership |
| 88 |
278001009 |
Female Terminal |
| 92 |
710000035 |
Female Housing (8 Circuits) |
| 98 |
Not |
Available As Spare Part - Open barrel |
| 101 |
278001392 |
Open Barrel Terminal |
| 102 |
293000070 |
SEALING CAP - Call your local BRP dealership |
| 106 |
278001005 |
Male Housing, 2 Circuits |
| 107 |
278000997 |
Male Housing, 3 Circuits |
| 110 |
278000631 |
Male Terminal |
| 112 |
278000632 |
Female Terminal |
| 115 |
278002378 |
Male Housing This part replaces 409207000. |
| 123 |
710001540 |
CONNECTOR_MALE 6 CAVITIES - Call your local BRP dealership This part replaces 278000736. |
| 127 |
409207600 |
Male Lock, 3 Circuits |
| 139 |
409014800 |
MALE TERMINAL - Call your local BRP dealership |
| 140 |
409015100 |
FEMALE TERMINAL - Call your local BRP dealership |
| 142 |
710000044 |
MALE HOUSING, 3 CIRCUITS - Call your local BRP dealership |
| 143 |
710000045 |
MALE TERMINAL HOUSING, 4 CIRCUITS - Call your local BRP dealership |
| 148 |
515175249 |
FEMALE TERMINAL HOUSING, 3 CIRC. - Call your local BRP dealership |
| 150 |
409015400 |
FEMALE HOUSING, 6 CIRCUITS - Call your local BRP dealership |
| 154 |
710000043 |
MALE LOCK, 3 CIRCUITS - Call your local BRP dealership |
| 155 |
710000046 |
MALE LOCK, 4 CIRCUITS - Call your local BRP dealership |
| 160 |
515175248 |
Female Lock, 3 Circuits |
| 162 |
409014900 |
FEMALE LOCK, 6 CIRCUITS - Call your local BRP dealership |
| 165 |
515175303 |
PLUG - Call your local BRP dealership |
| 186 |
219704424 |
Vinyl Tubing, Low Temp 3000Mm Long |
| 196 |
293750002 |
Tie Wrap 142 mm |
| 197 |
710000051 |
Female Terminal |
| 198 |
710000032 |
Female Terminal Housing, 4 Circ. |
| 199 |
710000050 |
WIRE SEAL - Call your local BRP dealership |
| 200 |
710000049 |
Cap |
| 221 |
409204600 |
FEMALE TERMINAL HOUSING, 24 CIRCUITS - Call your local BRP dealership |
| 222 |
409204300 |
Female Housing |
| 227 |
409004300 |
Male Terminal |
| 228 |
409007300 |
Female Terminal |
| 229 |
278000223 |
Female Terminal |
| 232 |
278000281 |
Female Terminal Housing, 3 Circuits |
| 236 |
278000219 |
CONNECTOR_MALE 1 CAVITY - Call your local BRP dealership |
| 242 |
278000218 |
Wire Seal |
| 243 |
710000048 |
Wire Seal |
| 245 |
710000028 |
Female Lock, 2 Circuits |
| 247 |
710000027 |
Female Terminal |
| 252 |
710000026 |
FEMALE TERMINAL HOUSING, 2 CIRCUITS - Call your local BRP dealership |
| 253 |
219704425 |
Tubing 6 Mm 3000Mm Long |
| 254 |
219704399 |
Was 409901700 Tubing (9 mm) |
| 255 |
219704400 |
Was 409901800 Tubing (13 mm) |
| 257 |
219704398 |
Was 409901600 Tubing 19mm |
| 280 |
409012100 |
Female Terminal |
| 285 |
710000078 |
HOUSING-TAB - Call your local BRP dealership |
| 286 |
409012300 |
Seal |
| 288 |
710000076 |
Resistance |
| 296 |
278000770 |
Insulated Sheath |
| 297 |
278001007 |
Insulated Sheath |
| 301 |
Not |
Available As Spare Part - Diode |
| 312 |
710000107 |
MALE HOUSING, 5 CIRCUITS - Call your local BRP dealership |
| 322 |
710000153 |
Female Terminal Housing, 3 Circ. |
| 329 |
710000082 |
Female Terminal |
| 435 |
Not |
Available As Spare Part - Receptacle |
