| Ref | Part Number | Description |
|---|
| 11 |
0336842 |
CLIP, SPRING |
| 35 |
0336388 |
GASKET, Manifold to block - Port |
| 36 |
0336389 |
GASKET, Manifold to block - Stbd |
| 37 |
0318165 |
DISPOSITIF DE RETENUE, tringlerie de carburateur |
| 38 |
0335739 |
SCREW, Conn. brkt. to mntg. brkt. |
| 39 |
0434522 |
ENSEMBLE COLLECTEUR, tube d'équilibrage |
| 40 |
0436893 |
ENSEMBLE COLLECTEUR D’ADMISSION, bâbord |
| 41 |
0436894 |
ENSEMBLE COLLECTEUR D’ADMISSION, tribord |
| 44 |
0326952 |
NIPPLE, Primer |
| 46 |
0343269 |
LINK, Port to stbd. carburetor |
| 47 |
0389823 |
CLAPET |
| 52 |
0436609 |
AIR SILENCER Assy |
| 54 |
0432639 |
GALET, contre-came |
| 56 |
0335257 |
LEVER, Linkage adjustment |
| 60 |
HOSE, |
Vent to air silencer, 2 in. (50mm) |
| 62 |
0323626 |
SCREW |
| 63 |
0335729 |
RETAINER, Balance tube |
| 64 |
0335818 |
SEAL, Manifold to carburetor, port |
| 65 |
0335819 |
JOINT, collecteur vers carburateur, tribord |
| 66 |
HOSE, |
Balance tube drain, 15 in., (381mm) por |
| 67 |
0324678 |
JOINT TORIQUE Galet de came de papillon |
| 69 |
0336821 |
GASKET, Air Silencer |
| 0433690 |
0439007 |
CARBURETOR ASSY., Port, 90 This part replaces 0433690. |
| 0433691 |
0439008 |
CARBURETOR ASSY., Stbd., 90 This part replaces 0433691. |
| 0433692 |
5001062 |
CARBURETOR ASSY., Port This part replaces 0433692. |
| 0433693 |
0439209 |
CARBURETOR ASSY., Stbd. This part replaces 0433693. |
