| Ref | Part Number | Description |
|---|
| 1 |
3852468 |
GASKET, Manifold to engine This part replaces 0909314. |
| 1 |
3852472 |
GASKET, Manifold to engine This part replaces 0909613. |
| 2 |
3852218 |
BRACKET, Oil cooler This part replaces 0383448. |
| 3 |
0979803 |
CLAMP |
| 4 |
0981158 |
OIL COOLER ASEMBLY |
| 4 |
0983849 |
OIL COOLER This part replaces 0981157. |
| 5 |
0306519 |
SCR,Coil clamp |
| 6 |
0315901 |
SCREW, Trans to adaptor |
| 6 |
0317444 |
SCREW, Adaptor |
| 7 |
0303269 |
L'WASHER, Upper |
| 9 |
0308335 |
CLAMP, Coil |
| 10 |
0982824 |
OIL LINE, Trans to cooler |
| 11 |
0120255 |
LOCKWASHER |
| 12 |
0909812 |
HOSE, Water pump to cooler |
| 12 |
0909814 |
HOSE, Water pump to clr |
| 13 |
0315744 |
ADAPTOR, Except 1 1 |
| 14 |
0912627 |
CLAMP This part replaces 0313851. |
| 14 |
3853786 |
CLAMP INSTRUMENT CABLE This part replaces 0980577. |
| 15 |
3853236 |
SLEEVE, Ignition coil This part replaces 0308716. |
| 16 |
0909830 |
CAP, Manifold |
| 16 |
3852476 |
CAP, Manifold This part replaces 0909829. |
| 17 |
0908438 |
HOSE |
| 18 |
0909689 |
SET SCREW |
| 18 |
0909690 |
SET SCREW |
| 19 |
0909863 |
ELBOW, Exhaust |
| 20 |
0316365 |
LOCKNUT,Stud adapter |
| 20 |
0908700 |
NUT |
| 21 |
0909786 |
GASKET |
| 22 |
0120177 |
L'WASHER, Alternator to brkt |
| 23 |
0909413 |
EXHAUST MANIFOLD |
| 23 |
0912441 |
EXHAUST MANIFOLD, Starboard This part replaces 0909280. |
| 23 |
0912442 |
EXHAUST MANIFOLD, Port This part replaces 0910144. |
| 24 |
0302858 |
GOUPILLE, fendue - Tringlerie de verrouillage de marche arrière |
| 26 |
0306435 |
SCREW, Brace to alternator |
| 28 |
3852140 |
STUD, Manifold to engine This part replaces 0315829. |
| 28 |
3852467 |
STUD, Manifold to engine This part replaces 0909313. |
| 29 |
0908700 |
NUT |
| 30 |
0306502 |
SCREW, Cable clip |
| 31 |
0316316 |
PIVOT |
| 33 |
0306872 |
BOLT, Flywheel |
| 33 |
0312855 |
SCREW |
| 34 |
0301552 |
LOCKWASHER |
| 35 |
0910580 |
CONNECTOR |
| 36 |
3852604 |
CLAMP, Exhaust This part replaces 0981323. |
| 40 |
0314898 |
L'NUT, Stud, alt frt |
| 41 |
0909817 |
HOSE, Therm to oil cooler |
| 42 |
0328742 |
NUT This part replaces 0306338. |
| 43 |
0908649 |
ELBOW, Oil cooler to oil line |
| 44 |
3853786 |
CLAMP INSTRUMENT CABLE This part replaces 0980577. |
| 46 |
0315149 |
SCREW, Adaptor |
| 47 |
0310896 |
SCREW |
| 48 |
0384053 |
TRANSMISSION ASSY L.H. 1 1 |
| 48 |
0384054 |
TRANSMISSION L.H. 1.52 1 |
| 48 |
0384055 |
TRANSMISSION L.H. 1.91 1 |
| 48 |
0384211 |
TARNSMISSION ASSY, 1 1 r.h. |
| 48 |
0384212 |
TRANSMISSION R.H. 1.52 1 |
| 48 |
0384213 |
TRANSMISSION R.H. 1.91:1 |
| 48 |
0980826 |
TRANSMISSION L.H. 2.57 1 |
| 48 |
0980827 |
TRANSMISSION R.H. 2.57 1 |
| 48 |
0980828 |
TRANSMISSION L.H. 2.91 1 |
| 48 |
0980829 |
TRANSMISSION R.H. 2.91 1 |
| 48 |
0981472 |
TRANSMISSION ASSY L.H. 1 1 |
| 48 |
0981473 |
TRANSMISSION ASSY R.H. 1 1 |
| 48 |
0981474 |
TRANSMISSION L.H. 1.52 1 |
| 48 |
0981475 |
TRANSMISSION R.H. 1.52 1 |
| 48 |
0981476 |
TRANSMISSION L.H. 1.91:1 |
| 48 |
0981477 |
TRANSMISSION L.H. 1.91 1 |
| 48 |
0981478 |
TRANSMISSION L.H. 2.57 1 |
| 48 |
0981479 |
TRANSMISSION R.H. 2.57 1 |
| 48 |
0981480 |
TRANSMISSION L.H. 2.91 1 |
| 48 |
0981481 |
TRANSMISSION R.H. 2.91 1 |
| 49 |
0384067 |
NEUTRAL SAFETY SW |
| 50 |
0316238 |
COUPLING 4", Shaft - 1 " |
| 50 |
0316239 |
COUPLING 4" SHAFT - 1.12" |
| 50 |
0316240 |
COUPLING 4", Shaft - 1.25" |
| 50 |
0316241 |
COUPLING 4", Shaft - 1.38" |
| 50 |
0316242 |
COUPLING 4", Shaft - 1.50" |
| 50 |
0908907 |
COUPLING, 5", prop shaft - 1" |
| 50 |
0908908 |
COUPLING, 5", prop shaft - 1.12" |
| 50 |
0908909 |
COUPLING, 5", shaft - 1.25 |
| 50 |
0908910 |
COUPLING, 5", prop shaft - 1.38" |
| 50 |
0908911 |
COUPLING, 5", prop shaft - 1.50" |
| 51 |
0316313 |
BRACKET |
| 52 |
0316314 |
CABLE CLIP |
| 53 |
0316315 |
ADAPTER |
| 54 |
0909251 |
PLUG, Cooler |
| 55 |
0909662 |
SPACER, Stud to adapter housing |
| 56 |
0910005 |
STUD |
| 58 |
0312329 |
NUT |
| 59 |
0909836 |
PLATE, Elbow, water shut off |
| 60 |
0379757 |
DRAIN COCK |
| 61 |
0909843 |
ELBOW, High rise |
