| Ref | Part Number | Description |
|---|
| 10b |
234042600 |
Flat Washer 4 mm, Stainless |
| 10c |
241142560 |
Hex. Flange Screw K40 X 25 |
| 10d |
291002818 |
DECK NOSE - Call your local BRP dealership |
| 10e |
291004291 |
Carpet |
| 10f |
291003580 |
LH Front Carpet |
| 10g |
291003581 |
ANTI SLIP MAT FR - Call your local BRP dealership |
| 10h |
291004299 |
ANTI SLIP MAT CTRL L - Call your local BRP dealership |
| 10j |
291004300 |
Carpet |
| 10k |
291004289 |
Carpet |
| 10m |
291004290 |
Carpet |
| 10n |
291004336 |
Carpet |
| 10p |
291004337 |
Carpet |
| 10q |
291004295 |
LH SPACER - Call your local BRP dealership |
| 10r |
291004296 |
RH SPACER - Call your local BRP dealership |
| 10s |
250000879 |
Plastite Torx Screw M6.81X30 |
| 40 |
293250259 |
GASKET - Call your local BRP dealership |
| 50 |
293250365 |
NEOPRENE SEAL - Call your local BRP dealership |
| 60 |
293250200 |
NEOPRENE SEAL - Call your local BRP dealership |
| 65 |
293730010 |
Black Dart |
| 69 |
219704381 |
SEAL 1000MM LONG - Call your local BRP dealership |
| 70 |
291004595 |
Front Module |
| 73 |
269002893 |
CASE - Call your local BRP dealership |
| 74 |
293150123 |
Pop Rivet 3/16" |
| 75 |
291004210 |
SEAT PIVOT - Call your local BRP dealership |
| 76 |
293150123 |
Pop Rivet 3/16" |
| 80 |
243163560 |
Plastite Hex. Screw M6.8 X 35 |
| 90 |
234082600 |
Flat Washer 8 mm, Stainless |
| 250 |
291002626 |
LH Nonskid |
| 260 |
291002937 |
RH NONSKID - Call your local BRP dealership |
| 310 |
293150016 |
Rivet 1/8" |
| 320 |
293000014 |
Black, Snap Cap |
| 400 |
292000933 |
U-Clamp |
| 420 |
291002351 |
Hook |
| 430 |
291001386 |
Black, Finition Plate |
| 450 |
234082600 |
Flat Washer 8 mm, Stainless |
| 460 |
232581200 |
Hex. Elastic Nut M8 Brass |
| 470a |
291004622 |
Black Rear Handle |
| 470b |
291003878 |
Seat Stud |
| 470c |
232100600 |
Hex. Jam Nut M10 |
| 470d |
234002600 |
Flat Washer 10 mm, Stainless |
| 470e |
271001732 |
Elastic Nut M10 Housing |
| 475 |
219704378 |
Gasket 3000Mm Long |
| 485 |
207065560 |
Hex. Screw M6 x 55 |
| 490 |
234062600 |
Flat Washer M6, Stainless |
| 500 |
232561200 |
Brass Elastic Stop Nut M6 |
| 510 |
207164060 |
Hex. Screw M6 X 40 |
| 520 |
250200022 |
Flat Washer M6.6 X 22 |
| 750b |
269502408 |
Housing Nut M6 This part replaces 269501166. |
| 750c |
219903184 |
CAUTION ENGINE OIL - Call your local BRP dealership |
| 820d |
241141660 |
Hex. Flange Screw K40 X 16 |
| 820g |
211100002 |
Push Nut |
| 820h |
241142560 |
Hex. Flange Screw K40 X 25 |
| 830d |
241141660 |
Hex. Flange Screw K40 X 16 |
| 830g |
211100002 |
Push Nut |
| 830h |
241142560 |
Hex. Flange Screw K40 X 25 |
| 850 |
293150123 |
Pop Rivet 3/16" |
| 950 |
291004640 |
LH COSMETIC - Call your local BRP dealership This part replaces 291004243. |
| 960 |
291004242 |
RH Cosmetic |
| 970 |
293150123 |
Pop Rivet 3/16" |
| 1030 |
291004275 |
Front Bumper |
| 1050 |
250000399 |
Hexagonal Cap Screw M6 X35 |
| 1060 |
291004274 |
Rear Bumper |
| 1080 |
250000399 |
Hexagonal Cap Screw M6 X35 |
| 1090 |
291004451 |
Black, Side Bumper |
| 1110 |
250000399 |
Hexagonal Cap Screw M6 X35 |
| 1160 |
291002744 |
Bumber Cap |
| 1300 |
513033435 |
Grommet |
| 1310 |
414523600 |
Elbow Fitting |
| 1320 |
219704356 |
Was 275500008 Hose 12 mm |
| 1330 |
293750001 |
Tie Wrap 94 mm |
| 2300a1 |
232561200 |
Brass Elastic Stop Nut M6 |
| 2300a2 |
205364060 |
SOCKET HEAD SCREW M6 X 40 - Call your local BRP dealership |
| 2300b1 |
241731260 |
Oval Philipp Screw KA30 x 12 |
| 2300b2 |
219704363 |
ROPE 3/16 3000MM LONG - Call your local BRP dealership |
| 2300b3 |
234032600 |
Flat Washer M3, Stainless |
| 2300b4 |
291002762 |
INSIDE COVER - Call your local BRP dealership |
| 2300b5 |
204100049 |
PHILLIPS TAPPING SCREW #8 X 1 - Call your local BRP dealership |
| 2300c |
291002726 |
BUTTON - Call your local BRP dealership |
| 2300d |
291002754 |
Button Cap |
| 2300e |
291002729 |
ROPE GUIDE - Call your local BRP dealership |
| 2310 |
291002724 |
FRONT REWINDER COVER - Call your local BRP dealership |
| 2320 |
205364560 |
SOCKET SCREW HEAD M6 X 45 - Call your local BRP dealership |
| 2330 |
291002755 |
DOUBLE CAGE NUT ASS'Y - Call your local BRP dealership |
| 2350 |
291002727 |
UNDER CAM - Call your local BRP dealership |
| 2360 |
291002755 |
DOUBLE CAGE NUT ASS'Y - Call your local BRP dealership |
| 2365 |
205364560 |
SOCKET SCREW HEAD M6 X 45 - Call your local BRP dealership |
| 2370 |
291002948 |
REWIND COVER - Call your local BRP dealership |
| 2375 |
205063560 |
Socket Head Screw M6 X 35 |
| 2380 |
234061600 |
Stainless Flat Washer M6 |
| 2385 |
232561200 |
Brass Elastic Stop Nut M6 |
| 2390 |
234042600 |
Flat Washer 4 mm, Stainless |
