09- Frame - With Locking Rear Differential_30C1402a
Parts (8)
| Ref | Part Number | Description |
|---|---|---|
| 1 | 705202876 | REAR DIFFERENTIAL SUPPORT - Call your local BRP dealership |
| 2 | 233281414 | Hex. Flange Elastic Nut M8 |
| 3 | 705203673 | LOWER DIFFERENTIAL SUPPORT - Call your local BRP dealership |
| 4 | 705203674 | SPACER - Call your local BRP dealership |
| 5 | 705203675 | SPACER - Call your local BRP dealership |
| 6 | 207604044 | Hex. Flange Screw M10 X 40 |
| 7 | 233201436 | Hex. Flange Elastic Nut M10 |
| 8 | 707601209 | HEAT SHIELD - Call your local BRP dealership |
