| Ref | Part Number | Description |
|---|
| 100 |
705008941 |
FENDER FL B-365 - Call your local BRP dealership |
| 100 |
705008942 |
Quarry Gray RH Front Fender |
| 100 |
705009666 |
TIMELESS BLACK LH FRONT FENDER - Call your local BRP dealership This part replaces 705009666. |
| 100 |
705011796 |
PAINTED TIMELESS BLACK RH FRONT FENDER - Call your local BRP dealership This part replaces 705009667. |
| 300 |
705009672 |
GULFSTREAM BLUE LH FENDER TRIM - Call your local BRP dealership |
| 300 |
705009673 |
Gulfstream Blue RH Fender Trim |
| 410 |
517302785 |
Edge Clip |
| 420 |
250000202 |
Self Tapping Screw #8 X 5/8 |
| 430 |
250000720 |
Torx Screw K50 X 16 |
| 440 |
293150104 |
Pop Rivet 3/16" |
| 500 |
705011801 |
Painted Timeless Black Lh Cover Fender This part replaces 705009680. |
| 500 |
705011802 |
Painted Timeless Black Rh Cover Fender This part replaces 705009681. |
| 610 |
517303756 |
Grommet |
| 620 |
705003264 |
Grommet |
| 700 |
705008947 |
HOOD LH B-365 - Call your local BRP dealership |
| 700 |
705008948 |
Quarry Gray RH Fixe Hood |
| 700 |
705011789 |
Painted Hyper Silver Lh Fixed Hood This part replaces 705009708. |
| 700 |
705011790 |
Painted Hyper Silver Rh Fixed Hood This part replaces 705009709. |
| 810 |
414644300 |
Black, Dart |
| 820 |
250100198 |
Panel Nut M6 X 1.0 This part replaces 250000048. |
| 830 |
250000722 |
Torx Screw M6 X 20 |
| 910 |
250100198 |
Panel Nut M6 X 1.0 This part replaces 250000048. |
| 920 |
250000722 |
Torx Screw M6 X 20 |
| 925 |
234062670 |
Stainless Steel Flat Washer |
| 930 |
705003841 |
Support Plate |
| 940 |
517302785 |
Edge Clip |
| 950 |
250000760 |
Torx Screw Truss Head K50X20 T20 |
| 960 |
293150104 |
Pop Rivet 3/16" |
| 970 |
705006623 |
Clamp |
| 975 |
207662054 |
Hex. Flange Screw M6 X 20 |
| 980 |
233261414 |
Hex. Flange Elastic Nut M6 x 1.0 |
| 985 |
234062670 |
Stainless Steel Flat Washer |
| 1010 |
705005156 |
Oval Washer |
| 1300 |
705007352 |
WHITE LH BUMPER CAP - Call your local BRP dealership |
| 1300 |
705009711 |
Gulfstream Blue LH Bumper Cap |
| 1300 |
705010791 |
TRIM_BUMPER FL B-101 - Call your local BRP dealership |
| 1400 |
705007353 |
WHITE RH BUMPER CAP - Call your local BRP dealership |
| 1400 |
705009712 |
TRIM_BUMPER RH B-352 - Call your local BRP dealership |
| 1400 |
705010792 |
TRIM_BUMPER FR B-101 - Call your local BRP dealership |
| 1410 |
250000760 |
Torx Screw Truss Head K50X20 T20 |
| 1420 |
250000724 |
Torx Screw M5 X 20 |
| 1430 |
250000958 |
Panel Nut M5 X 0.8 This part replaces 250000079. |
| 1440 |
250200025 |
Washer M5 |
| 1500 |
705005784 |
Front Radiator Grille |
| 1510 |
705006635 |
Radiator Grille Bracket |
| 1520 |
250000721 |
Torx Truss Screw M6 X 16 |
| 1600 |
705005983 |
LH Rear Radiator Grille |
| 1650 |
293830005 |
Rubber Bumper |
| 1700 |
705005984 |
RH Rear Radiator Grille |
| 1710 |
517302785 |
Edge Clip |
| 1740 |
250000958 |
Panel Nut M5 X 0.8 This part replaces 250000079. |
| 1750 |
250000724 |
Torx Screw M5 X 20 |
| 1760 |
250200025 |
Washer M5 |
| 1800 |
705004508 |
LH Front Facia |
| 1800 |
705004509 |
RH Front Facia |
| 1910 |
250000758 |
Torx Screw M6 X 25 |
| 1920 |
233261414 |
Hex. Flange Elastic Nut M6 x 1.0 |
| 1930 |
250000712 |
Torx Screw M6 X 20 |
| 1940 |
233261414 |
Hex. Flange Elastic Nut M6 x 1.0 |
| 2100 |
705005992 |
LH Front Facia Trim |
| 2100 |
705005993 |
RH Front Facia Trim |
| 2300 |
705006078 |
LH Front Facia Support |
| 2300 |
705006079 |
RH Front Facia Support |
| 2410 |
250000760 |
Torx Screw Truss Head K50X20 T20 |
| 2420 |
250100198 |
Panel Nut M6 X 1.0 This part replaces 250000048. |
