| Ref | Part Number | Description |
|---|
| 7a |
708200959 |
LH Bumper Trim |
| 7b |
250000759 |
Torx Truss Pt K40 X 16 |
| 7c |
708200960 |
RH Bumper Trim |
| 7d |
250000759 |
Torx Truss Pt K40 X 16 |
| 7f |
710004901 |
Connector Plug |
| 7g |
710010204 |
Clip |
| 7h |
708400406 |
Lighting Harness Connector Cap |
| 7j |
250001123 |
Hex. Flange Screw K40 X 16 |
| 7k |
710004901 |
Connector Plug |
| 7m |
710010204 |
Clip |
| 7n |
710010204 |
Clip |
| 7p |
707000995 |
Pressure And Temperature Sensor |
| 7q |
207662554 |
Hex. Flange Screw M6 X 25 |
| 7r1 |
269500252 |
M6 Nut Housing Ass'y |
| 7r2 |
232561600 |
Hex. Elastic Stop Nut M6 |
| 7s |
710004764 |
AAPTS Harness |
| 7t |
705003464 |
Cap |
| 100f |
293740092 |
Velcro Strip |
| 100g |
390401400 |
Rivet |
| 100h |
234031600 |
Flat Washer 3 mm, Stainless Steel |
| 110 |
293830005 |
Rubber Bumper |
| 120a |
269500252 |
M6 Nut Housing Ass'y |
| 120b |
232561600 |
Hex. Elastic Stop Nut M6 |
| 130 |
705019020 |
Battery Cover Ass'y |
| 135 |
250000767 |
Torx Truss Screw M6 X 12 |
| 140 |
705011444 |
Fuse Cover Ass'y |
| 150 |
710002858 |
Rubber Plug |
| 160 |
708400166 |
Cap |
| 170 |
708304274 |
Soft Box Liner |
| 180 |
293740092 |
Velcro Strip |
| 200 |
708201071 |
Deep Black, Upper Box Support |
| 210 |
705003911 |
Spring |
| 220 |
705018738 |
Latch |
| 225 |
207663544 |
Hex. Flange Screw M6 X 35 |
| 227 |
233261414 |
Hex. Flange Elastic Nut M6 x 1.0 |
| 230 |
293250529 |
Neoprene Seal 1420MM |
| 240 |
293150230 |
Tuflok Plastic Rivet |
| 250 |
207661644 |
Hex. Flange Screw M6 X 16 |
| 255 |
232561434 |
Elastic Stop Nut M6 |
| 300 |
219704387 |
Gasket 4100Mm Long |
| 310 |
219704424 |
Vinyl Tubing, Low Temp 3000Mm Long |
| 400 |
708201076 |
Deep Black, Front Bumper |
| 410a |
708201124 |
Upper Bumper Trim |
| 430 |
250000760 |
Torx Screw Truss Head K50X20 T20 |
| 440 |
250000755 |
Torx Screw M6 X 16 |
| 450 |
293150230 |
Tuflok Plastic Rivet |
| 460 |
708201084 |
Sensor Support |
| 470 |
250001131 |
Torx Truss PT K40 x 12 |
| 500 |
708200879 |
Deep Black, LH Inner Air Scoop |
| 510 |
250001131 |
Torx Truss PT K40 x 12 |
| 520 |
250000712 |
Torx Screw M6 X 20 |
| 600 |
708200880 |
Deep Black, RH Inner Air Scoop |
| 610 |
250001131 |
Torx Truss PT K40 x 12 |
| 620 |
250000712 |
Torx Screw M6 X 20 |
| 700 |
708201086 |
Deep Black, LH Exterior Scoop |
| 710 |
293150230 |
Tuflok Plastic Rivet |
| 720 |
250001131 |
Torx Truss PT K40 x 12 |
| 800 |
708201087 |
Deep Black, RH Exterior Scoop |
| 810 |
293150230 |
Tuflok Plastic Rivet |
| 820 |
250001131 |
Torx Truss PT K40 x 12 |
| 900 |
708200970 |
Black Epoxy, Air Scoop Grille |
| 910 |
705004838 |
Flat Clip |
| 920 |
250001131 |
Torx Truss PT K40 x 12 |
| 1000a |
708200869 |
Bare, Front Hood |
| 1010 |
705002223 |
Lug |
| 1011 |
232180600 |
Hex. Jam Nut M8 |
| 1012 |
234081410 |
Flat Washer 8 mm |
| 1013 |
233281464 |
Elastic Flange Nut M8 |
| 1020 |
708200886 |
Black, Hood Hinge |
| 1025 |
207561244 |
Hex. Flange Screw M6 X 12, Scotch Grip |
| 1030 |
705003322 |
Spacer |
| 1031 |
230663084 |
Hex. Flange Screw M6 X 130 |
| 1032 |
233261414 |
Hex. Flange Elastic Nut M6 x 1.0 |
| 2560 |
210262050 |
Hexagonal Head Screw |
| 2570 |
250001051 |
Screw-Forming Hex.HD.FL. M6 X 16 |
