08- Drive System, Rear Differential_13T1504b
Parts (25)
| Ref | Part Number | Description |
|---|---|---|
| 10 | 233201436 | Hex. Flange Elastic Nut M10 |
| 12 | 250001041 | Hex. Flange Screw M10 X 135 This part replaces 250000508. |
| 26 | 293750008 | Tie Wrap 368 mm |
| 53 | 705500504 | Fill Level Plug |
| 54 | 705500506 | Copper Washer |
| 79 | 705501556 | Oil Seal |
| 80 | 705501584 | Breather Tube |
| 85 | 705501724 | Plug Drain |
| 87 | 219704410 | Polyurethane Hose 10000Mm Long |
| 89 | XXX | Not Available As Spare Parts |
| 91 | 705501896 | Rear Differential Ass'y |
| 113 | 705502051 | REAR COVER - Call your local BRP dealership |
| 114 | 705502052 | Rear Pinion Cover |
| 115 | 705502053 | Pinion 10 Teeth |
| 116 | 705502682 | Gear 36 Teeth This part replaces 705502054. |
| 117 | 705502055 | Ball Bearing |
| 118 | 705502737 | Ball Bearing This part replaces 705502056. |
| 119 | 705502738 | Ball Bearing This part replaces 705502057. |
| 120 | 705502058 | Needle Bearing |
| 121 | 705502059 | Nut |
| 122 | 705502060 | Differential Shim 0.02 mm |
| 123 | 705502061 | Pinion Gear Shim 1.67 mm |
| 124 | 705502062 | Oil Seal |
| 125 | 705502063 | Screw |
| 126 | 705502064 | Seal |
