| Ref | Part Number | Description |
|---|
| 25 |
506152758 |
Heating Element 32 Watt 2 Wires |
| 35 |
219704427 |
LOW TEMPERATURE TUBING 1/2? 3000MM LONG - Call your local BRP dealership |
| 50 |
506153176 |
Thermal Insulation This part replaces 506152548. |
| 400a |
250000352 |
Hex. Flange Screw M8 X 40 |
| 410a |
506152751 |
Steering Support This part replaces 506152750. |
| 420 |
250000852 |
Hex. Flange Screw M8 X 1.25 x 40 |
| 430 |
250000852 |
Hex. Flange Screw M8 X 1.25 x 40 |
| 520 |
506152460 |
Moulding Strap |
| 540 |
250000779 |
Torx Screw M6 X 1.0 X 18, Scotch Grip |
| 1000 |
506152962 |
Steering Column |
| 1010 |
506152508 |
Upper Half-Housing |
| 1012 |
506152588 |
Lower Half-Housing |
| 1014 |
506152509 |
Upper Anti-Vibration Gasket |
| 1016 |
506152518 |
Lower Vibration Ring |
| 1020 |
506152297 |
Housing Bushing |
| 1021 |
207667056 |
Hex. Flange Screw M6 X 70 This part replaces 207667086. |
| 1022 |
233261416 |
Elastic Flange Nut M6 X 1.0 |
| 1030 |
506152297 |
Housing Bushing |
| 1031 |
207667056 |
Hex. Flange Screw M6 X 70 This part replaces 207667086. |
| 1032 |
233261416 |
Elastic Flange Nut M6 X 1.0 |
| 1040 |
506152297 |
Housing Bushing |
| 1041 |
207667056 |
Hex. Flange Screw M6 X 70 This part replaces 207667086. |
| 1042 |
233261416 |
Elastic Flange Nut M6 X 1.0 |
| 1050 |
506152297 |
Housing Bushing |
| 1051 |
207667056 |
Hex. Flange Screw M6 X 70 This part replaces 207667086. |
| 1052 |
233261416 |
Elastic Flange Nut M6 X 1.0 |
| 1060 |
506152163 |
Plate |
| 1220 |
207004034 |
Hex. Screw M10 X 1.5 X 40 |
| 1230 |
233601466 |
Elastic Locking Nut M10 |
| 1250a |
506152482 |
Tie-Rod |
| 1250c |
250100016 |
LH Threaded Hex. Jam Nut M10 |
| 1250c |
732610010 |
RH Threaded Hex. Jam Nut M10 |
| 1250d |
506152081 |
LH Thread Ball Joint |
| 1250d |
506152684 |
RH Threaded Ball Joint |
| 1260 |
503192496 |
Washer |
| 1280 |
506152582 |
Washer |
| 1290 |
Not |
Available As Spare Part - Not Applicable |
| 1300 |
233201464 |
Hex. Flange Elastic M10 x 1.5 |
