| Ref | Part Number | Description |
|---|
| 1 |
515178473 |
Démarreur This part replaces 515177389. |
| 2 |
415129355 |
Speedometer Button |
| 3 |
234061410 |
Rondelle Plate 6 mm |
| 3 |
415129370 |
Gauge Ring |
| 4 |
278003012 |
Relais Démarreur This part replaces 278002347. |
| 4 |
415129349 |
Lens |
| 5 |
207561644 |
Vis À Épaulement M6 X 16, Scotch Grip |
| 5 |
516006224 |
BRP Logo 20MM x 2MM This part replaces 219902677. |
| 7 |
515176274 |
Halogen Bulb, 60/55 W, 12 V ( H4 ) |
| 8 |
515176774 |
Relais, 30 AMP |
| 8 |
Not |
Available As Spare Part - Bulb Holder |
| 9 |
515176498 |
Cap |
| 9 |
515176775 |
Relais, 50 AMP |
| 10 |
219800280 |
Rubber Cap Protector This part replaces 515176499. |
| 10 |
710001026 |
Couvercle De Fusible |
| 11 |
250000722 |
Torx Screw M6 X 20 This part replaces 250000128. |
| 11 |
515175811 |
Pince À Fusible - Appelez votre concessionnaire BRP local |
| 12 |
250100198 |
Panel Nut M6 X 1.0 This part replaces 250100113. |
| 12 |
710000742 |
Mini-Fusible, 5 Ampères |
| 12 |
710000743 |
Mini-fusible, 7.5 Ampères |
| 12 |
710000744 |
Mini Fusible, 10 Amperes |
| 12 |
710000745 |
Mini-Fusible, 15 Ampères |
| 12 |
710000746 |
Mini-Fusible, 20 Ampères |
| 12 |
710000747 |
Mini-Fusible, 30 Ampères |
| 13 |
515176780 |
Fil De Masse |
| 14 |
515175232 |
Male Terminal |
| 14 |
M28015 |
Gaine - Appelez votre concessionnaire BRP local |
| 15 |
515175494 |
Male Housing, 3 Circuits |
| 15 |
515176805 |
Câble De Batterie |
| 16 |
278001771 |
Capuchon Protecteur - Appelez votre concessionnaire BRP local |
| 16 |
409902000 |
Tubing 12 mm |
| 17 |
278002963 |
Safety Nut (DESS Switch) |
| 17 |
570151000 |
Capuchon Protecteur |
| 18 |
515178284 |
DESS This part replaces 515177057. |
| 19 |
233261414 |
Hex. Flange Elastic Nut M6 x 1.0 |
| 19 |
250000282 |
Ens. Boulon De Batterie This part replaces 295500849. |
| 20 |
234461608 |
External Serrated Lock Washer 6 mm |
| 20 |
510005079 |
Couvercle De Batterie |
| 21 |
510005143 |
Courroie De Batterie |
| 22 |
515175670 |
Female Terminal Housing, 2 Circuits |
| 22 |
515176804 |
Support De Batterie |
| 23 |
278000632 |
Female Terminal |
| 23 |
510005146 |
Couvre Courroie |
| 24 |
516005892 |
Décalque De Fusible ETEC - Appelez votre concessionnaire BRP local |
| 25 |
515176366 |
Air Temperature Sensor |
| 25 |
515177073 |
Support De la Boîte De Fusible - Appelez votre concessionnaire BRP local |
| 26 |
389804300 |
Push Nut |
| 26 |
515176806 |
Câble De Démarrage |
| 27 |
219704425 |
Tubing 6 Mm 3000Mm Long |
| 27 |
515176795 |
Ancrage Tie Rap (vissable) |
| 28 |
278002704 |
Diagnostic Connector This part replaces 278002148. |
| 28 |
605627000 |
Attache |
| 29 |
414115200 |
Attache 180 mm |
| 30 |
515175232 |
Male Terminal |
| 31 |
710000667 |
Male Housing, 2 Circuits |
| 32 |
515177289 |
Ground Wire This part replaces 515176861. |
| 33 |
515177272 |
Capacitor |
| 34 |
516005515 |
CAPACITOR DECAL (ENGLISH) - Call your local BRP dealership |
| 35 |
515177193 |
Cap |
| 36 |
514054856 |
Temperature Sensor |
| 37 |
414227300 |
Clip |
| 38 |
219704425 |
Tubing 6 Mm 3000Mm Long |
| 41 |
293750001 |
Tie Wrap 94 mm |
| 41 |
293750002 |
Tie Wrap 142 mm |
| 41 |
293750008 |
Tie Wrap 368 mm |
| 41 |
414115200 |
Tie-Rap 180 mm |
| 42 |
515177502 |
WIRING HARNESS MAIN - Call your local BRP dealership |
| 43 |
250200026 |
Lock washer |
| 44 |
710001248 |
DC Outlet |
| 45 |
250000462 |
Socket Head Screw M10 X 32 |
| 46 |
515177837 |
Visor Harness This part replaces 515177187. |
| 47 |
572103300 |
Cap |
| 48 |
515175851 |
Extension |
| 49 |
515176607 |
Capacitor Support |
| 50 |
515176605 |
Capacitor Harness |
| 51 |
207063544 |
Hex. Flange Screw M6 X 35 |
| 52 |
515177125 |
Compressor Module |
