| Ref | Part Number | Description |
|---|
| 2 |
410914600 |
Plastic Clip, Spark Plug Wire |
| 3 |
278002198 |
SPARK PLUG WIRE - Call your local BRP dealership This part replaces 278001268. |
| 5 |
409207100 |
FEMALE LOCK, 2 CIRCUITS - Call your local BRP dealership |
| 6 |
278000632 |
Female Terminal |
| 7 |
409207300 |
Female Connector, 2 Circuits |
| 8 |
278000237 |
SPARK PLUG CAP - Call your local BRP dealership |
| 9 |
219703120 |
Spark Plug NGK BR9ES This part replaces 414961100. |
| 11 |
516000245 |
Electrical Box Decal |
| 12 |
219704453 |
Was 293550004 Dielectric Grease, 150 g |
| 13 |
293750001 |
Tie Wrap 94 mm |
| 14 |
710001540 |
CONNECTOR_MALE 6 CAVITIES - Call your local BRP dealership This part replaces 278000736. |
| 15 |
278000737 |
MALE LOCK, 6 CIRCUITS - Call your local BRP dealership |
| 16 |
278000632 |
Female Terminal |
| 17 |
293000052 |
Sealing Cap |
| 19 |
278000998 |
Female Terminal |
| 20 |
278001005 |
Male Housing, 2 Circuits |
| 21 |
278000999 |
Wire Seal |
| 22 |
515175303 |
PLUG - Call your local BRP dealership |
| 23 |
219704424 |
Vinyl Tubing, Low Temp 3000Mm Long |
| 24 |
Not |
Available As Spare Part - Female Lock Deutsch |
| 25 |
409015100 |
FEMALE TERMINAL - Call your local BRP dealership |
