| Ref | Part Number | Description |
|---|
| 2 |
420233677 |
BUSHING - Call your local BRP dealership |
| 3 |
711233680 |
Bushing |
| 4 |
420632010 |
Center Pin 8 X 12 This part replaces 290632010. |
| 5 |
420229302 |
Location Pin 10 M6x50 This part replaces 711229301. |
| 6 |
420929650 |
Drive Pin 5 X 10 |
| 7 |
711247320 |
Sleeve |
| 8 |
711430550 |
Oil Seal |
| 9 |
420230395 |
OIL SEAL - Call your local BRP dealership |
| 10 |
420932822 |
Ball Bearing This part replaces 711932826. |
| 11 |
711232501 |
Ball Bearing 6303 |
| 12 |
420232764 |
Ball Bearing 6205 This part replaces 711232764. |
| 13 |
420932816 |
Ball Bearing This part replaces 711932815. |
| 14 |
420256322 |
Oil Sieve This part replaces 711256321. |
| 15 |
711256430 |
Oil Sieve Guide |
| 16 |
420941928 |
Taptite Screw M5 X 16 This part replaces 420941925. |
| 17 |
711250910 |
Gasket |
| 18 |
420932830 |
BALL 8 MM - Call your local BRP dealership |
| 19 |
711239280 |
Compression Spring |
| 20 |
711256170 |
Valve Pin Screw |
| 21 |
711241822 |
Socket Head Screw M6 x 45 |
| 22 |
711241810 |
Socket Head Screw M6 x 35 |
| 23 |
711240531 |
Socket Head Screw M6 x 75 |
| 24 |
711241262 |
Socket Head Screw M6 x 65 |
| 25 |
711220762 |
Oil Pump Shaft |
| 26 |
711220760 |
Oil Pump Shaft |
| 27 |
420232731 |
Needle Pin This part replaces 711232730. |
| 28 |
420256681 |
Oil Pump Rotor, Suction This part replaces 711256680. |
| 29 |
420256671 |
Oil Pump Rotor, Pressure This part replaces 711256670. |
| 30 |
711210642 |
Oil Pump Cover |
| 31 |
420640823 |
Torx Head Screw M5 X 16 This part replaces 711640821. |
| 32 |
420827590 |
Thrust Washer This part replaces 711827590. |
| 33 |
420232431 |
Needle Pin This part replaces 711232430. |
| 34 |
711234560 |
Oil Pump Gear (25 Teeth) |
| 35 |
420245330 |
Snap Ring |
| 36 |
711256330 |
Hose Nipple |
| 37 |
711924245 |
Angle Tube |
| 38 |
420552280 |
Crush Washer This part replaces 711552280. |
| 39 |
420840278 |
Drain Plug M18 X 1.5 This part replaces 711840277. |
| 40 |
420950141 |
Sealing Ring |
| 41 |
205081660 |
Socket Head Screw M8 X 16 |
| 42 |
420430622 |
O-Ring This part replaces 711430622. |
| 43 |
711240232 |
Plug Screw M16 x 1,5 |
| 44 |
711260570 |
Retaining Valve |
| 45 |
711256150 |
Valve Pin |
| 46 |
711239810 |
Spring (Compression) |
| 47 |
711256170 |
Valve Pin Screw |
| 48 |
420256188 |
Oil Filter This part replaces 711256188. |
| 49 |
420230923 |
O-Ring This part replaces 711650500. |
| 50 |
711610230 |
Oil Filter Cover |
| 51 |
205063044 |
Socket Head Screw M6 X 30 |
| 52 |
420856539 |
Inter.Press.Hui*Switch-Oil Pressure This part replaces 711256770. |
| 53 |
420241856 |
Position Switch This part replaces 711241852. |
| 54 |
711640470 |
Stud M10 x 223 |
| 55 |
293800060 |
Loctite 243, 10 ml |
| 56 |
293550030 |
Grease, Super Lube This part replaces 293550014. |
| 57 |
Not |
Available As Spare Part - Engine Oil, Mineral, API SJ SAE 10W40 |
| 58 |
219704464 |
Was 420297616 Klueber Grease, 60g |
| 59 |
293800073 |
Loctite 277, 10 ml |
| 60 |
710000112 |
OPEN BARREL - Call your local BRP dealership |
| 61 |
278001012 |
Male Housing, 1 Circuit |
| 62 |
278001014 |
Female Terminal |
