| Ref | Part Number | Description |
|---|
| 032 |
278000998 |
Female Terminal |
| 033 |
278000999 |
Wire Seal |
| 034 |
409010100 |
Female Terminal |
| 036 |
409010400 |
Female Terminal Housing, 1 Circuit |
| 044 |
515175231 |
Female Terminal |
| 054 |
515175495 |
Female Housing, 3 Circuits |
| 064 |
710000568 |
Male terminal housing |
| 077 |
409010300 |
Female Terminal |
| 099 |
278000992 |
Open Barrel |
| 103 |
710010053 |
RELAY This part replaces 410113200. |
| 106 |
278001005 |
Male Housing, 2 Circuits |
| 109 |
409209900 |
Female Housing, 5 Circuits |
| 110 |
278000631 |
Male Terminal |
| 112 |
278000632 |
Female Terminal |
| 126 |
409207500 |
Male Lock, 2 Circuits |
| 138 |
293000052 |
Sealing Cap |
| 172 |
561503100 |
FEMALE TERMINAL - Call your local BRP dealership |
| 173 |
561503100 |
FEMALE TERMINAL - Call your local BRP dealership |
| 188 |
409902000 |
Tubing 12 mm |
| 196 |
293750002 |
Tie-Rap 142 mm |
| 223 |
515175320 |
FEMALE TERMINAL - Call your local BRP dealership |
| 225 |
409202700 |
FEMALE TERMINAL HOUSING, 3 CIRCUITS - Call your local BRP dealership |
| 253 |
515175442 |
Tubing 6 mm |
| 254 |
409901700 |
Tubing 9 mm |
| 255 |
409901800 |
Tubing 13 mm |
| 256 |
415080000 |
Tubing 16 mm |
| 280 |
409012100 |
Female Terminal |
| 283 |
Not |
Available As Spare Part - Female Terminal Housing, 2 Circuits |
| 284 |
409012300 |
Seal |
| 286 |
409012300 |
Seal |
| 314 |
515176176 |
Female Terminal Housing, 3 Circuits |
| 319 |
515175568 |
Male Terminal |
| 320 |
515175567 |
Female Terminal |
| 347 |
278001674 |
Mâle Terminal Housing, 2 Circuits |
| 348 |
278001673 |
Female Terminal Housing, 2 Circuits |
| 349 |
278001672 |
Male Lock, 2 Circuits |
| 350 |
278001671 |
Female Lock, 2 Circuits |
| 355 |
515175658 |
Female Housing, 2 Circuits |
| 358 |
515175665 |
Male Terminal Housing, 2 Circuits |
| 363 |
515175670 |
Female Terminal Housing, 2 Circuits |
| 366 |
515175673 |
Male Housing, 6 Circuits |
| 368 |
515175675 |
Female Lock, 2 Circuits |
| 371 |
515175678 |
Male Wedge, 6 Circuits |
| 372 |
515175679 |
FEMALE LOCK, 12 CIRCUITS - Call your local BRP dealership |
| 382 |
515175704 |
FEMALE TERMINAL HOUSING, 12 CIRCUITS - Call your local BRP dealership |
| 409 |
515175812 |
Plug |
| 410 |
515175801 |
Female Housing, 24 Circuits |
| 411 |
515175802 |
Retainer Block |
| 412 |
515175803 |
Wire Seal |
| 415 |
515175806 |
Female Terminal |
| 420 |
414115200 |
Tie-Rap 180 mm |
| 443 |
710000335 |
Female Terminal |
| 498 |
710000399 |
Female Housing |
| 645 |
515176164 |
Male Terminal |
| 652 |
515176221 |
Female Housing |
| 653 |
515176222 |
Wire Seal |
| 654 |
515176223 |
Female Terminal Housing, 36 Circuits |
| 655 |
515176224 |
Terminal Support |
| 764 |
710000992 |
Clip |
| 804 |
515176523 |
FEMALE TERMINAL HOUSING, 2 CIRCUITS - Call your local BRP dealership |
| 827 |
710001119 |
Female Terminal |
| 831 |
710001131 |
Female Terminal |
| 865 |
515176530 |
Connector |
| 866 |
515176531 |
Terminal |
| 916 |
515176594 |
Seal |
