| Ref | Part Number | Description |
|---|
| 1 |
0382564 |
CABLE ASSEMBLY, Motor |
| 5 |
0314460 |
CONNECTOR, Housing |
| 7 |
0312691 |
SCREW, Cash pannel |
| 8 |
0386545 |
IGNITION SWITCH & KEY ASSY This part replaces 0379047. |
| 12 |
KEY,Ignition |
Ref: 13 0975257 SWITCH ASSEMBLLY 0975257 |
| 15 |
0900696 |
WASHER |
| 18 |
0381626 |
LEAD ASSEMBLY, Ignition to choke switch |
| 21 |
0307911 |
SCREW |
| 23 |
0382565 |
CABLE ASSY., Instrument |
| 37 |
0385407 |
BATTERY TERMINAL KIT This part replaces 0277708. |
| 39 |
0385407 |
BATTERY TERMINAL KIT This part replaces 0277709. |
| 0382566 |
0382566 |
INSTRUMENTS & CABLE ASSEMBLY |
