| Ref | Part Number | Description |
|---|
| 10 |
415131138 |
Airy Blue, Chassis Tunnel Module 154 |
| 10a11 |
518337274 |
Front Suspension Arm Reinforcement |
| 10a12 |
518337125 |
RH Rear Suspension Support |
| 10a13 |
518337124 |
LH Rear Suspension Support |
| 10a18 |
518329789 |
RH Footrest Reinforcement |
| 10a19 |
518332924 |
Deep Black, LH Chassis Reinforcement |
| 10a20 |
518329648 |
RH Roller |
| 10a21 |
518328452 |
LH Roller |
| 10a22 |
518336064 |
RH Footrest Reinforcement |
| 10a23 |
518336063 |
LH Footrest Reinforcement |
| 10a25 |
518335919 |
Radiator Tunnel 154 |
| 10a26 |
250300652 |
Protruding Stud M8 x 22 |
| 10a27 |
250100199 |
Insert Half Hex Body M6 x 1.0 |
| 10a28 |
293450369 |
Threaded Insert M6 X 1.0 |
| 10a3 |
518332803 |
Deep Black, RH Footrest Reinforcement |
| 10a31 |
518332481 |
Rear Cap |
| 10a32 |
250001151 |
Torx Button Head Screw M8 X 25 |
| 10a34 |
518331822 |
RH Footrest |
| 10a35 |
518332977 |
LH Footrest |
| 10a37 |
293150312 |
Rivet Ornit 4,8 X 11,3 |
| 10a38 |
293150313 |
Rivet Ornit 4,8 X 8,8 |
| 10a40 |
293150245 |
Henrob Rivet |
| 10a42 |
293150264 |
Rivet Ornit 6,5 X 10.5 |
| 10a43 |
293150265 |
Rivet Ornit 6,5 X 12.5 |
| 10a45 |
293150266 |
Ornit Rivet 6,5 X 14.5 |
| 10a6 |
518332802 |
Deep Black, LH Footrest Reinforcement |
| 10a7 |
518331712 |
LH Frame Corner 24 |
| 10a8 |
518331973 |
RH Frame Corner 24 |
| 20 |
293730052 |
Black, Plug |
| 25 |
293730052 |
Black, Plug |
| 35 |
518331727 |
RH Stirrup Reinforcement |
| 40 |
293450275 |
Insert |
| 42 |
250000717 |
Torx Head Screw M6 X 16 |
| 50 |
518331823 |
Heat Shield |
| 55 |
293450275 |
Insert |
| 60 |
250000717 |
Torx Head Screw M6 X 16 |
| 94 |
293450417 |
Insert_Threaded M6 X 1 |
| 95 |
293450275 |
Insert |
| 96 |
293450275 |
Insert |
| 170 |
293450267 |
Insert M5 - 0.8 |
| 200 |
518332541 |
Lateral Reinforcement |
| 205 |
207682044 |
Hex. Flange Screw M8 X 20 |
| 210 |
232081414 |
Hex. Nut M8 |
| 230 |
207562056 |
Hex. Flange Screw M6 X 20 |
| 425 |
207562056 |
Hex. Flange Screw M6 X 20 |
| 430 |
233261416 |
Elastic Flange Nut M6 X 1.0 |
| 860 |
518335168 |
Deep Black, LH Rear Footrest Reinforcement |
| 865 |
518335169 |
Deep Black, RH Rear Footrest Reinforcement |
| 875 |
293150268 |
Rivet Ornit 6,5 X 18.5 |
| 880 |
250001407 |
Screw Socket Head M6 X 16 |
| 885 |
233261466 |
Hex. Flange Elastic Nut M6 |
| 1160 |
293150266 |
Ornit Rivet 6,5 X 14.5 |
| 1170 |
518334031 |
Muffler Support Ass'y |
| 1400 |
293730047 |
Black, Dart 8 mm |
| 1405 |
293730060 |
Black, Dart 10 mm |
| 1700 |
518329982 |
Front Protector |
| 1710 |
293150308 |
Black, Ornit Rivet 3/16 X ,675 This part replaces 293150308. |
| 1800a |
518329979 |
Rear Protector |
| 1800b |
518333936 |
Central Protective Structure |
| 1800c |
250000577 |
Torx Truss Screw K40 X 12 |
| 1840 |
293150308 |
Black, Ornit Rivet 3/16 X ,675 This part replaces 293150308. |
| 3040 |
293730079 |
Dart |
| 3050 |
293150154 |
Magna-Grip Rivet 6.4 X 65,9 |
