EXHAUST ADAPTER
Parts (19)
| Ref | Part Number | Description |
|---|---|---|
| 4 | 5033841 | UNION, WATER RETURN |
| 6 | 5033587 | BOLT (8X70mm) |
| 9 | 5030541 | O RING |
| 10 | 5033611 | SEAL, OIL |
| 11 | 5033613 | SEAL, OIL |
| 13 | 5034127 | BOLT |
| 14 | 5033591 | WASHER (8.5X19X2.3mm) |
| 15 | 5033596 | Wave Wahser |
| 17 | 5036553 | BOLT, UPPER MOUNT This part replaces 5033560. |
| 18 | 5033561 | MOUNT, UPPER |
| 19 | 5030419 | NUT |
| 20 | 5033594 | WASHER (12.5X24X2.5mm) |
| 21 | 5033904 | WASHER (12X22X3.0mm) |
| 22 | 5033842 | MOUNT, UPPER THRUST REVERSE |
| 23 | 5033562 | COVER, UPPER MOUNT |
| 24 | *5031609 | BOLT |
| 25 | 5031221 | NUT |
| 26 | 5030057 | WASHER |
| 27 | 5033597 | WASHER (12.5X22X2.5mm) |
