| Ref | Part Number | Description |
|---|
| 1 |
0398754 |
ENGINE COVER ASSY. |
| 1 |
0398843 |
ENGINE COVER ASSY. |
| 1 |
0432547 |
ENGINE COVER ASSY. |
| 1 |
0432548 |
ENGINE COVER ASSY. |
| 2 |
0394976 |
LOCATING BRACKET, Rear |
| 3 |
0329762 |
LOCATING BRACKET, Front |
| 9 |
0397630 |
HOOK |
| 10 |
0334172 |
APPLIQUE, 300 rear |
| 11 |
0334171 |
PLATE, Rear |
| 12 |
0330086 |
APPLIQUE, V, front & rear |
| 13 |
0328009 |
TILT HANDLE |
| 14 |
0912173 |
SEAL, Engine cover |
| 15 |
0332862 |
PLATE, Rear |
| 16 |
0330076 |
APPLIQUE, Rear |
| 17 |
0330012 |
BAFFLE |
| 19 |
0330088 |
APPLIQUE, Front & rear |
| 21 |
0332860 |
PLATE, Applique front |
| 23 |
0330090 |
LOUVER, Engine cover, port |
| 24 |
0330091 |
LOUVER, Engine cover, port |
| 25 |
0332860 |
PLATE, Applique front |
| 26 |
0328608 |
BRACKET, Louver mounting., 300 |
| 27 |
0332862 |
PLATE, Rear |
| 28 |
0913073 |
LIFT HANDLE |
| 29 |
0334004 |
SCREW, Hook to bracket |
| 30 |
0341499 |
SOUND BLANKET, Top This part replaces 0330014. |
| 31 |
0330015 |
SOUND BLANKET, Rear |
| 32 |
0331633 |
SOUND BLANKET, Front |
| 33 |
0334150 |
SOUND BLANKET, Stbd. |
| 34 |
0334151 |
SOUND BLANKET, Port |
| 0397522 |
0397522 |
DECAL SET |
| 0398956 |
0398956 |
OWNER'S MANUAL |
