| Ref | Part Number | Description |
|---|
| B |
278001750 |
FEMALE TERMINAL - Call your local BRP dealership |
| B |
278001751 |
MALE HOUSING, 41 CIRCUITS - Call your local BRP dealership |
| B |
515175883 |
Latch |
| B |
515175884 |
LOCK - Call your local BRP dealership |
| B |
515175885 |
COVER - Call your local BRP dealership |
| B |
515175886 |
SEAL - Call your local BRP dealership |
| BD |
409012100 |
Female Terminal |
| BD |
409012300 |
Seal |
| BD |
710000081 |
Female Housing, 6 Circuits |
| BD |
710000840 |
Cap |
| BN1 |
710000913 |
Terminal |
| BN2 |
710000913 |
Terminal |
| BP |
710000913 |
Terminal |
| CA |
710001633 |
LOCK - Call your local BRP dealership |
| CA |
710001634 |
HOUSING - Call your local BRP dealership |
| CA |
710001905 |
Terminal Joint |
| CA |
710001906 |
Terminal |
| CAKX |
409209700 |
Female Housing, 4 Circuits |
| CC |
710000274 |
Female Terminal |
| CC |
710000848 |
Lock |
| CC |
710000849 |
Male Housing, 6 Circuits |
| CI |
515175801 |
Female Housing, 24 Circuits |
| CI |
515175802 |
Retainer Block |
| CI |
515175803 |
Wire Seal |
| CI |
515175806 |
Female Terminal |
| CI |
515175812 |
Plug |
| CI |
710000399 |
Female Housing |
| CI |
710001131 |
Female Terminal |
| CI2 |
278001665 |
Female Terminal |
| CI2 |
515175677 |
MALE WEDGE, 4 CIRCUITS - Call your local BRP dealership |
| CRD |
219704453 |
Was 293550004 Dielectric Grease, 150 g |
| CRD |
515175231 |
Female Terminal |
| CRD |
515175658 |
Female Housing, 2 Circuits |
| CRG |
219704453 |
Was 293550004 Dielectric Grease, 150 g |
| CRG |
515175231 |
Female Terminal |
| CRG |
515175658 |
Female Housing, 2 Circuits |
| CV |
278000631 |
Male Terminal |
| CV |
409207600 |
Male Lock, 3 Circuits |
| CV |
515175666 |
Male Housing |
| DB |
278001665 |
Female Terminal |
| DB |
293000052 |
Sealing Cap |
| DB |
515175678 |
Male Wedge, 6 Circuits |
| DB |
710001540 |
CONNECTOR_MALE 6 CAVITIES - Call your local BRP dealership |
| DC1 |
710000038 |
Female Terminal |
| DC2 |
710000038 |
Female Terminal |
| DC3 |
219704453 |
Was 293550004 Dielectric Grease, 150 g |
| DC3 |
515175231 |
Female Terminal |
| DC3 |
515175658 |
Female Housing, 2 Circuits |
| FP |
278001013 |
Wire Seal |
| FP |
278001014 |
Female Terminal |
| FP |
409209700 |
Female Housing, 4 Circuits |
| FRR |
219704453 |
Was 293550004 Dielectric Grease, 150 g |
| FRR |
515175231 |
Female Terminal |
| FRR |
515175658 |
Female Housing, 2 Circuits |
| FT |
278000217 |
Female Housing, 2 Circuits |
| FT |
278000218 |
Wire Seal |
| FT |
710000992 |
Clip |
| HIC |
278001665 |
Female Terminal |
| HIC |
515175672 |
CONNECTOR_MALE 4 CAVITIES - Call your local BRP dealership |
| HIC |
515175677 |
MALE WEDGE, 4 CIRCUITS - Call your local BRP dealership |
| MC1 |
710001435 |
HOUSING - Call your local BRP dealership |
| MC1 |
710001436 |
TERMINAL - Call your local BRP dealership |
| MD |
409012300 |
Seal |
| MD |
710000329 |
Male Housing, 4 Circuits |
| MD |
710000335 |
Female Terminal |
| MD |
710000840 |
Cap |
| MG1 |
409011300 |
Male Terminal |
| MG1 |
409012300 |
Seal |
| MG1 |
710000402 |
Wire Seal |
| MG1 |
710000835 |
Male Terminal Housing, 6 Circuits |
| MG2 |
409012100 |
Female Terminal |
| MG2 |
409012300 |
Seal |
| MG2 |
710000081 |
Female Housing, 6 Circuits |
| MG2 |
710000402 |
Wire Seal |
| MG3 |
409011300 |
Male Terminal |
| MG3 |
409012300 |
Seal |
| MG3 |
710000402 |
Wire Seal |
| MG3 |
710000835 |
Male Terminal Housing, 6 Circuits |
| PD |
278001013 |
Wire Seal |
| PD |
278001014 |
Female Terminal |
| PD |
710000780 |
Connector |
| PF1 |
278000999 |
Wire Seal This part replaces 710000838. |
| PF1 |
278002172 |
Foam |
| PF1 |
415128501 |
Seal |
| PF1 |
415129856 |
Fuse Box Base Ass´y This part replaces 710000660. |
| PF1 |
710000781 |
Fuse Puller |
| PF1 |
710000836 |
Female Terminal |
| PF1 |
710000837 |
Female Terminal |
| PF1 |
710000840 |
Cap |
| PF1 |
710001026 |
Fuse Cover |
| PF1 |
710001567 |
FUSE LOGO - Call your local BRP dealership |
| PF2 |
219704400 |
Was 409901800 Tubing (13 mm) |
| PF2 |
219704453 |
Was 293550004 Dielectric Grease, 150 g |
| PF2 |
233261494 |
Hex. Flange Elastic Nut M6 |
| PF2 |
710000496 |
PROTECTOR CAP - Call your local BRP dealership |
| PF2 |
710000913 |
Terminal |
| PF2 |
710001633 |
LOCK - Call your local BRP dealership |
| PF2 |
710001636 |
Terminal |
| PF2 |
710001637 |
SEAL - Call your local BRP dealership |
| PF2 |
710001711 |
Fuse Box |
| PF2 |
710001905 |
Terminal Joint |
| PG |
278001013 |
Wire Seal |
| PG |
278001014 |
Female Terminal |
| PG |
710000780 |
Connector |
| PR |
219704453 |
Was 293550004 Dielectric Grease, 150 g |
| PR |
515175231 |
Female Terminal |
| PR |
515175495 |
Female Housing, 3 Circuits |
| RD1 |
710000877 |
Female Terminal |
| RD1 |
710000879 |
Female Housing, 3 Circuits |
| RD1 |
710000881 |
Seal |
| RD1 |
710000882 |
Cap |
| RD2 |
710000877 |
Female Terminal |
| RD2 |
710000880 |
Housing, 3 Circuits |
| RD2 |
710000881 |
Seal |
| SS1 |
409010300 |
Female Terminal |
| SS2 |
409010300 |
Female Terminal |
| SW1 |
278001007 |
Insulated Sheath |
| SW1 |
710000421 |
Female Terminal |
| SW2 |
278001008 |
Insulated Sheath |
| SW2 |
278002261 |
Female Terminal |
| SW4 |
278000992 |
Open Barrel |
| SWRC |
278000223 |
Female Terminal |
| SWRC |
278000273 |
Male Housing, 3 Circuits |
| SWRC |
710000504 |
Wire Seal |
| SWW |
278000223 |
Female Terminal |
| SWW |
278000273 |
Male Housing, 3 Circuits |
| 10 |
710001047 |
Fuse, 40 AMP |
| 20 |
710001200 |
Fuse 30 amp. |
| 188 |
409902000 |
Tubing 12 mm |
| 196 |
293750002 |
Tie Wrap 142 mm |
| 253 |
219704425 |
Tubing 6 Mm 3000Mm Long |
| 254 |
219704399 |
Was 409901700 Tubing (9 mm) |
| 256 |
219704408 |
Tubing 16 Mm 1000Mm Long |
| 257 |
219704398 |
Was 409901600 Tubing 19mm |
| 260 |
219704423 |
Was 515175319 Tubing 22 mm |
| 301 |
409012700 |
Diode |
| 525 |
710000482 |
SHRINK TUBING - Call your local BRP dealership |
| 641 |
710000667 |
Male Housing, 2 Circuits |
| 666 |
710000742 |
Little Fuse, 5 Amperes |
| 667 |
710000743 |
Little Fuse, 7.5 Amperes |
| 670 |
710000746 |
Little Fuse, 20 Amperes |
| 672 |
710000748 |
Diode |
| 769 |
278002165 |
Bus Bar |
| 778 |
278002165 |
Bus Bar |
| 889 |
710001233 |
Seal |
| 890 |
710001229 |
Terminal |
| 921 |
710001340 |
Female Terminal |
| 930 |
515176621 |
Wire Seal |
| 961 |
710001446 |
Male Housing Terminal, 6 Circuits |
| 1002 |
710001630 |
Terminal |
