| Ref | Part Number | Description |
|---|
| 1 |
0432708 |
SWIVEL BRACKET This part replaces 0320625. |
| 1 |
0432710 |
SWIVEL BRACKET This part replaces 0320626. |
| 5 |
0321035 |
BRUSHING, Swivel bracket |
| 6 |
0320866 |
RONDELLE DE BUTÉE, arbre d'articulation |
| 7 |
0392518 |
STEERING ARM ASSY. This part replaces 0387222. |
| 7 |
0392519 |
STEERING ARM ASSY. This part replaces 0387223. |
| 8 |
0320865 |
THRUST WASAHER |
| 9 |
0320942 |
KEEPER PIVOT SHAFT |
| 10 |
0338942 |
COVER, Mount bracket lower This part replaces 0320864. |
| 11 |
0322000 |
SCREW, Starter to crankcase |
| 12 |
0320621 |
MOUNT BRACKET |
| 13 |
0320746 |
CROU, support de montage |
| 15 |
0320516 |
EXHAUST HOUSING,Outer |
| 15 |
0435318 |
EXHAUST HOUSING, Outer This part replaces 0320628. |
| 16 |
0328698 |
SCREW, Adapter to crankcase This part replaces 0908931. |
| 18 |
0387243 |
RUBBER MOUNT, Lower, std. |
| 18 |
0387998 |
RUBBER MOUNG,Hi performance |
| 19 |
0318612 |
SCREW, Bracket to cover This part replaces 0321737. |
| 20 |
0307708 |
RONDELLE GROWER |
| 21 |
0320961 |
JOINT, boîtier d'engrenages vers carter intérieur |
| 22 |
0320640 |
COVER, Exhaust housing, rear |
| 23 |
SEAL,Cover |
Ref: 24 0327800 EXH. HSG., Inner, upper This part replaces 0320664. 0327800 |
| 25 |
0320639 |
COVER, Exhause housing front, alum |
| 27 |
0346897 |
TUBE WATER, Inlet This part replaces 0321016. |
| 27 |
0346898 |
TUBE WATER, Inlet This part replaces 0321015. |
| 28 |
0305145 |
GROMMET |
| 29 |
0324516 |
GASKET, Adapter to plate, 150 This part replaces 0321086. |
| 30 |
0320578 |
ADAPTER,Exhaust housing |
| 31 |
0302479 |
VIS, démarreur vers bloc cylindres-carter |
| 32 |
0303459 |
ECREW,Exhaust cover,1-1/2"long |
| 33 |
0306778 |
ECREW,Exhaust cover,1-3/8"long |
| 35 |
0306418 |
VIS, ancrage |
| 36 |
0306409 |
VIS, collecteur vers carter-moteur |
| 37 |
0323214 |
GASKET, Adap. to pwrhd, 175 This part replaces 0321026. |
| 38 |
0387098 |
RUBBER MOUNT ASSY., Upper |
| 39 |
0311416 |
SCREW, Adapter to cylinder |
| 40 |
0307708 |
RONDELLE GROWER |
| 41 |
0335612 |
SCREW, Upper This part replaces 0316406. |
| 42 |
0322624 |
WASHER, Lag screw This part replaces 0313169. |
| 43 |
0317894 |
CACHE, tube de relevage |
| 44 |
0323599 |
LOCKNUT This part replaces 0316828. |
| 45 |
0320623 |
STERN BRACKET,Starboard |
| 47 |
0335553 |
TILT TUBE This part replaces 0321052. |
| 49 |
0320792 |
PIN |
| 51 |
0321541 |
WASHER,Shock absorber pin |
| 52 |
0321054 |
SPRING CLIP |
| 53 |
0363254 |
NUT, Stern bracket screw This part replaces 0321861. |
| 54 |
0307238 |
RONDELLE |
| 55 |
0320248 |
RONDELLE, écrou |
| 56 |
0318273 |
Bolt hex retainer 1/2 in. |
| 57 |
0319886 |
SCREW |
| 58 |
0318572 |
Bolt thread protective cap 1/2 in. |
| 59 |
0318573 |
SCREW, Bracket mount, 3 1/2 in. (12.7 x 89mm) |
| 61 |
0436541 |
ROD Assy, Thrust This part replaces 0387278. |
| 62 |
0321053 |
SORUBG,Thrust rod |
| 64 |
0396309 |
STERN BRACKET ASSEMBLY, Port This part replaces 0320622. |
| 65 |
0387560 |
LOCKING LEVER,Rod |
| 66 |
0321229 |
SEAL, Cover to housing |
| 67 |
0327796 |
EXHASUT HSG,Inner lower This part replaces 0320838. |
| 67 |
0327797 |
EXHAUST HOUSING, Inner lower This part replaces 0320839. |
| 68 |
0320870 |
TUNING MEGAPHONE |
| 71 |
0320936 |
JOINT, boîtier échappement, inférieur |
| 72 |
0319883 |
SCREW, Exhaust cover |
| 73 |
0329109 |
SHOULDER SCREW This part replaces 0321389. |
| 74 |
0316355 |
BUT, Carburetor mounting This part replaces 0315204. |
| 76 |
0315071 |
SCREW |
| 77 |
0317222 |
SCREW |
| 78 |
0388291 |
GASKET & PLATE ASSY. |
| 79 |
0323222 |
GASKET, Inner exh. hsg to meg This part replaces 0322312. |
| 80 |
0321396 |
SPACER,Trail lock |
| 84 |
0581535 |
SENDING UNIT ASSY. |
| 85 |
0328742 |
NUT This part replaces 0308133. |
| 86 |
0511419 |
SPRING |
| 87 |
0511420 |
NUT |
| 91 |
0321735 |
SUPPORT, Stern bracket |
