| Ref | Part Number | Description |
|---|
| 10 |
715010631 |
Magma Red, LH Upper Suspension Arm Ass'y With Balljoint This part replaces 706205150. |
| 20 |
715010632 |
Magma Red, RH Upper Suspension Arm Ass'y With Balljoint This part replaces 706205151. |
| 21a |
XXX |
Not Available As Spare Parts |
| 21b |
XXX |
Not Available As Spare Parts |
| 21c |
XXX |
Not Available As Spare Parts |
| 24 |
408200700 |
Grease Fitting |
| 30 |
715010624 |
Magma Red, LH Lower Suspension Arm Ass'y With Balljoint This part replaces 706205152. |
| 40 |
715010625 |
Magma Red, RH Lower Suspension Arm Ass'y With Balljoint This part replaces 706205153. |
| 50 |
207607046 |
Hex. Flange Screw M10 X 70 |
| 60 |
233201436 |
Hex. Flange Elastic Nut M10 |
| 70 |
706203084 |
Ball Joint |
| 80 |
706202045 |
Ball Joint |
| 100 |
293150104 |
Pop Rivet 3/16" |
| 160 |
706202135 |
RH CV joint Guard |
| 170 |
706202134 |
LH CV joint Guard |
| 210 |
706205517 |
LH Knuckle |
| 220 |
706205047 |
RH Knuckle This part replaces 706205518. |
| 230 |
293370035 |
Circlip |
| 240 |
250100239 |
Hex Nut M12 |
| 241 |
706200281 |
Hardened Washer |
| 250 |
211400017 |
Cotter Pin |
| 270 |
207605546 |
Hex. Flange Screw M10 X 55 |
| 300 |
706204869 |
Stabilizer Bar Ass'y |
| 310 |
706203437 |
Clamp |
| 320 |
706205240 |
Stabilizer Bar Bushing |
| 330 |
293550056 |
Grease Fitting 90° |
| 340 |
250000951 |
Hex. Flange Screw DIN.6921 |
| 350 |
250001195 |
Elastic Flange Nut M12 |
| 360 |
706204803 |
LH Link Stabilizer Bar |
| 370 |
706204804 |
RH Link Stabilizer Bar |
