| Ref | Part Number | Description |
|---|
| 10 |
277002298 |
Steering Column |
| 15 |
277002180 |
Deep Black, Handlebar |
| 20 |
277001874 |
Wear Ring |
| 30g |
506152820 |
Spring |
| 37 |
277002313 |
Plate |
| 38 |
205583060 |
Socket Head Screw M8 X 30, Scotch Grip |
| 40a |
XXX |
Not Available As Spare Parts |
| 45 |
250000834 |
Hex. Screw Flange DIN.6921 S.Grip |
| 60n |
250001237 |
Socket Head Screw M4 X 16 |
| 60q |
250200114 |
Sealing Washer |
| 60r |
234042600 |
Flat Washer 4 mm, Stainless |
| 65 |
250000922 |
Torx Truss Screw M6 X 16 |
| 70 |
277002299 |
Gauge Support |
| 110 |
277002330 |
Deep Black / Lava Grey, Steering Pad |
| 111 |
277002377 |
Steering Pad Spacer |
| 112 |
250001381 |
Screw Torx Truss Head M6 X 30 |
| 130 |
277002349 |
RH Upper Lever Trim |
| 140 |
277002350 |
RH Lower Lever Trim |
| 145 |
250000922 |
Torx Truss Screw M6 X 16 |
| 180 |
277002398 |
LH Front Lever Trim Ass'y |
| 190 |
277002368 |
Red, Switch Button |
| 200 |
277002138 |
Hand Lever Accelerator |
| 220 |
250001087 |
Flange Screw Plastite #10, 14 X 7/8" |
| 235 |
241142560 |
Hex. Flange Screw K40 X 25 |
| 236 |
234042600 |
Flat Washer 4 mm, Stainless |
| 240 |
277001945 |
Reverse Handle |
| 260 |
250001087 |
Flange Screw Plastite #10, 14 X 7/8" |
| 275 |
241142560 |
Hex. Flange Screw K40 X 25 |
| 276 |
234042600 |
Flat Washer 4 mm, Stainless |
| 280 |
277002351 |
LH Upper Lever Trim |
| 290 |
277002352 |
LH Lower Lever Trim |
| 295 |
250000922 |
Torx Truss Screw M6 X 16 |
| 330 |
277002399 |
RH Front Lever Trim Ass'y |
| 355a |
277001958 |
Deep Black, LH Handle Grip |
| 355b |
277001946 |
Deep Black, RH Handle Grip |
| 400 |
277002296 |
Steering Column Trim |
| 440 |
295501183 |
Steering Arm Kit |
| 450 |
295501183 |
Steering Arm Kit |
| 470 |
277001654 |
Spacer |
| 510a |
277001987 |
Arm |
| 510b |
250000399 |
Hexagonal Cap Screw M6 X35 |
| 510c |
277002085 |
C Clamp |
| 530 |
277002119 |
End Fitting Cable |
| 540a |
211100056 |
Hex. Nut 1/4"-28 |
| 545 |
211100056 |
Hex. Nut 1/4"-28 |
| 550 |
277001582 |
Wiper Rod |
| 555 |
277001583 |
End Piece |
| 560 |
293830063 |
Rubber Washer |
| 570 |
277001856 |
Ring Halves |
| 580 |
250000399 |
Hexagonal Cap Screw M6 X35 |
| 630 |
277000775 |
Ball Joint |
| 640a |
250000969 |
Hex Screw SEMS M6X35, SS |
| 690 |
250000399 |
Hexagonal Cap Screw M6 X35 |
| 710b |
269502544 |
Nut Housing M6 |
| 720 |
277002318 |
Wear Ring |
| 750 |
277001605 |
Steering Support Pivot |
| 760 |
207168060 |
Hex Screw M6 X 80 |
| 770 |
234062600 |
Flat Washer M6, Stainless |
| 780 |
277001996 |
Adjustment Handle |
| 781 |
293830005 |
Rubber Bumper |
| 785 |
269502544 |
Nut Housing M6 |
| 790 |
277002010 |
Lock |
| 800 |
277001652 |
Pivot |
| 810 |
207064060 |
Hex. Screw M6 X 40 |
| 820 |
234062600 |
Flat Washer M6, Stainless |
| 895 |
276000520 |
Corrugated Sheath 22MM - 1250MM |
| 905 |
277002150 |
Rope Guide |
| 1100a |
234062600 |
Flat Washer M6, Stainless |
| 1100b |
250000002 |
Hex. Screw M6 X 30, Scotch Grip |
| 1100c |
277000203 |
Black, Cap |
