| Ref | Part Number | Description |
|---|
| 20a |
278000217 |
Female Housing, 2 Circuits |
| 30a |
278000222 |
Male Terminal |
| 40a |
278000218 |
Wire Seal |
| 50a |
204130208 |
SPRING - Call your local BRP dealership |
| 60a |
204130209 |
CLEVIS, STAINLESS STEEL - Call your local BRP dealership |
| 70a |
204100229 |
PHILLIPS HD.SHOULDER SCREW - Call your local BRP dealership |
| 90a |
204390526 |
BRACKET, STAINLESS STEEL - Call your local BRP dealership |
| 100a |
207151660 |
HEX. SCREW M5 X 16 - Call your local BRP dealership |
| 110a |
232551600 |
Hex. Elastic Nut M5 |
| 120a |
234052600 |
Flat Washer 5 mm, Stainless |
| 300 |
277001744 |
ETC Control Shifter Ass'y |
| 310 |
277001705 |
CONTROL BRACKET - Call your local BRP dealership |
| 315 |
204100137 |
TAPPING SCREW 1/4-20 X 1/2 - Call your local BRP dealership |
| 320 |
207163060 |
Hex. Screw M6 X 30 |
| 330 |
234062600 |
Flat Washer M6, Stainless |
| 340 |
204100089 |
FLAT WASHER 9/32? - Call your local BRP dealership |
| 400 |
277001693 |
THROTTLE CABLE - Call your local BRP dealership |
