| Ref | Part Number | Description |
|---|
| 1 |
0432153 |
CYLINDER & C'CASE ASSY. This part replaces 0397381. |
| 1 |
0434158 |
CYLINDER & C'CASE ASSY.,175 This part replaces 0397081. |
| 6 |
0316988 |
SCREW, Lockplate cyl. to c'case |
| 7 |
0322411 |
DEFLECTOR, Water pass |
| 9 |
0309577 |
LOCK PLATE |
| 10 |
0324813 |
ECREW,Exhaust cover,1-3/8"long This part replaces 0324565. |
| 13 |
0394884 |
CHECK VALVE |
| 14 |
0328004 |
COVER, Bypass |
| 16 |
0319292 |
SCREW, Clamp |
| 18 |
0376349 |
FIL, masse |
| 19 |
0306049 |
SCREW |
| 21 |
0320745 |
GASEKT,Cylinder head,150 |
| 21 |
0335361 |
GASKET, Cylinder head, 175 This part replaces 0325647. |
| 22 |
0328325 |
CYL. HEAD, Stbd. |
| 22 |
0332137 |
CYLINDER HEAD, Stbd 175 |
| 23 |
0321028 |
GASKET Cover |
| 24 |
0320840 |
COVER, Cylinder head |
| 25 |
0306409 |
VIS, collecteur vers carter-moteur |
| 26 |
0307267 |
SCREW |
| 27 |
0386941 |
SPARK PLUB,Champion L77J4 |
| 27 |
0502180 |
SPARK PLUG, Champion QL77JC4 This part replaces 0387633. |
| 28 |
0386686 |
SWITCH TEMP |
| 29 |
0328324 |
CYL. HEAD, Port |
| 29 |
0332136 |
CYL. HEAD, Port 175 |
| 30 |
0326308 |
ECH.COVER,Inner,150,175,200 |
| 31 |
0336432 |
EXHAUST COVER Inner, 175 This part replaces 0329379. |
| 32 |
0328005 |
COVER, Bypass cover |
| 33 |
0329381 |
O-RING, Manifold, 175 |
| 35 |
0329380 |
O-RING, Manifold, 175 |
| 37 |
0336429 |
SEAL, Exhaust manifold, 175 This part replaces 0323625. |
| 38 |
0329494 |
COVER, Exhaust outer |
| 38 |
0336433 |
COVER, Exhaust outer, 175 This part replaces 0329495. |
| 39 |
0321182 |
GASKET, Inner cover |
| 39 |
0393561 |
GASKET, Inner cover, 175 This part replaces 0329378. |
| 40 |
0317972 |
ACREW,Exh manf to cyl.,4-1/4" long |
| 40 |
0323218 |
SCREW, Exh. manf. to cyl., 127mm (5") |
| 40 |
0323626 |
SCREW |
| 40 |
0324424 |
SCREW, Carb. body, long |
| 40 |
0909533 |
SCREW, Pressure relief valve cover |
| 41 |
0913435 |
HOSE, Elbow to drain tee This part replaces 0327720. |
| 45 |
0330151 |
CLAMP, Harness to oil tank boss This part replaces 0309322. |
| 47 |
0321221 |
SEAL, Pressure release |
| 48 |
0321220 |
RETAINER, Spring valve |
| 49 |
0321013 |
COVER, Thermostat |
| 50 |
0306778 |
ECREW,Exhaust cover,1-3/8"long |
| 51 |
0321184 |
GASHKET,Thermostatcover |
| 52 |
5005440 |
THERMOSTAT This part replaces 0393659. |
| 53 |
0310058 |
GASKET, Thermostat |
| 54 |
0321222 |
CUP, Valve seat |
| 55 |
0320880 |
SEAT |
| 56 |
0321027 |
VALVE, Preasure realese |
| 57 |
0317245 |
SPRING, Control valve |
| 58 |
0306418 |
VIS, ancrage |
| 60 |
0330151 |
CLAMP, Harness to oil tank boss This part replaces 0309322. |
| 61 |
0313581 |
BUMBER, Mount screw |
| 62 |
0319218 |
SUPPORT BNRACE,Stbd. |
| 63 |
0319217 |
PIN,Clevis to shift lock |
| 66 |
0307133 |
GASKET |
| 67 |
0303398 |
VIS, support |
| 68 |
0303398 |
VIS, support This part replaces 0302030. |
| 69 |
0394621 |
LOW COMPRESSION CYL. HEAD KIT |
| 70 |
0391988 |
POWERHEAD GASKET SET |
| 70 |
0394885 |
POWERHEAD GASKET SET |
