| Ref | Part Number | Description |
|---|
| 1 |
219704413 |
Was 415084700 Protective Shield |
| 2 |
519000014 |
Coolant Tank |
| 3 |
509000187 |
Pressure Cap This part replaces 414684700. |
| 4 |
219704410 |
Polyurethane Hose 10000Mm Long |
| 5 |
408800400 |
TRIDON GEAR CLAMP - Call your local BRP dealership |
| 7 |
415012300 |
RADIATOR PROTECTOR - Call your local BRP dealership |
| 8 |
Not |
Available As Spare Part - Rivet |
| 9 |
408803400 |
Clamp Tridon |
| 10 |
414795800 |
Radiator Hose |
| 12 |
415010400 |
Engine Inlet Hose |
| 13 |
414973000 |
Radiator Outlet Hose |
| 15 |
414728700 |
Temperature Sensor |
| 517290711 |
LH |
Radiator 517290711 |
| 517290711 |
Radiateur |
GA 517290711 |
