| Ref | Part Number | Description |
|---|
| 1 |
0172048 |
PANEL & STUD ASSEMBLY |
| 2 |
0172055 |
LEAD ASSEMBLY |
| 3 |
0121891 |
ELBOW |
| 4 |
0979924 |
CABLE ASSEMBLY |
| 9 |
0386545 |
IGNITION SWITCH & KEY ASSY |
| 11 |
0379852 |
INDICATING LIGHT ASSY., Oil |
| 13 |
0908726 |
BULB, #53R |
| 14 |
0378334 |
FUSE HOLDER & LEAD ASSEMBLY |
| 16 |
0121807 |
PLUG, Large |
| 17 |
0172053 |
AMP-FUEL GAUGE ASSY |
| 18 |
0121720 |
BITTON,Trim |
| 23 |
0328737 |
RONDELLE, levier de sens de marche et manette des gaz This part replaces 0306561. |
| 24 |
0980550 |
AMMETER |
| 25 |
0121354 |
MOUNTING SCREW, Instrument |
| 27 |
0121996 |
BUSHING |
| 28 |
0172060 |
LEAD ASSEMBLY, Ground |
| 29 |
0309024 |
PLUG |
| 30 |
0121810 |
PLUG, Switch hole |
| 31 |
0121824 |
PLUG |
| 32 |
0121811 |
CLAMP, Mounting |
| 35 |
0304642 |
LOCKWASHER |
| 37 |
0121350 |
BRACKET |
| 41 |
3853800 |
OIL PRESSURE SENDER This part replaces 0172127. |
| 42 |
0172735 |
GAUGE, Water temperature |
| 44 |
3855776 |
ADAPTER, Oil sender This part replaces 0121688. |
| 45 |
0172057 |
OIL PRESS./WATER TEMP. GAUGE |
| 47 |
0328737 |
RONDELLE, levier de sens de marche et manette des gaz This part replaces 0306561. |
| 50 |
0121720 |
BITTON,Trim |
| 51 |
0172058 |
CONNECTOR WIRE |
| 54 |
0304141 |
LOCKWASHER |
| 55 |
0172051 |
TACHOMETER ASSEMBLY |
| 56 |
0121354 |
MOUNTING SCREW, Instrument |
| 58 |
0304642 |
LOCKWASHER |
| 59 |
0121720 |
BITTON,Trim |
| 61 |
0172140 |
GROUND WIRE ASSEMBLY |
| 63 |
0311086 |
CONNECTOR, Pipe |
| 0121687 |
0121687 |
FITTING |
| 0171759 |
0171759 |
CASE ASSEMBLY |
