| Ref | Part Number | Description |
|---|
| 010 |
278001211 |
MALE CONNECTOR, 26 CIRCUITS - Call your local BRP dealership |
| 020 |
278000995 |
FEMALE TERMINAL - Call your local BRP dealership |
| 030 |
278001223 |
Seal |
| 040 |
278001005 |
Male Housing, 2 Circuits |
| 060 |
293000070 |
SEALING CAP - Call your local BRP dealership |
| 070 |
278000994 |
FEMALE TERMINAL - Call your local BRP dealership |
| 080 |
278000997 |
Male Housing, 3 Circuits |
| 090 |
278000998 |
Female Terminal |
| 100 |
278000999 |
Wire Seal |
| 110 |
278001003 |
Male Connector, 2 Circuits |
| 120 |
409013900 |
SEAL - Call your local BRP dealership |
| 130 |
278001480 |
MALE CONNECTOR, 2 CIRCUITS - Call your local BRP dealership |
| 140 |
278001481 |
Female Terminal |
| 150 |
278001482 |
Seal |
| 160 |
278001483 |
LOCK, 2 CIRCUITS - Call your local BRP dealership |
| 170 |
278000998 |
Female Terminal |
| 180 |
278000999 |
Wire Seal |
| 190 |
Not |
Available As Spare Part - Tubing 16 mm |
| 200 |
278001003 |
Male Connector, 2 Circuits |
| 210 |
278000223 |
Female Terminal |
| 220 |
278000218 |
Wire Seal |
| 230 |
278001484 |
RUBBER CAP - Call your local BRP dealership |
| 240 |
Not |
Available As Spare Part - Tubing 10 mm |
| 250 |
Not |
Available As Spare Part - Tubing 6 mm |
| 260 |
Not |
Available As Spare Part - Tubing 8 mm |
| 280 |
278000220 |
Male Connector, 2 Circuits |
| 290 |
293750001 |
Tie Wrap 94 mm |
| 300 |
293750002 |
Tie Wrap 142 mm |
| 320 |
278001308 |
MALE CONNECTOR, 4 CIRCUITS - Call your local BRP dealership |
| 330 |
278001210 |
FEMALE TERMINAL - Call your local BRP dealership |
| 340 |
278001114 |
Female Terminal |
| 350 |
Not |
Available As Spare Part - Tubing 19 mm |
