| Ref | Part Number | Description |
|---|
| 4 |
207066044 |
Hex. Screw M6 X 60 |
| 5 |
207685044 |
Hex. Flange Screw M8 X 50 |
| 11 |
224061201 |
Flat Washer |
| 12 |
233261414 |
Hex. Flange Elastic Nut M6 x 1.0 |
| 13 |
233281414 |
Hex. Flange Elastic Nut M8 |
| 16 |
250000283 |
Torx Screw M8 X 25, Scotch Grip |
| 17 |
250000761 |
Torx Truss Screw M8 X 50 This part replaces 250000298. |
| 18 |
250000712 |
Torx Screw M6 X 20 |
| 19 |
250100242 |
Threaded Insert M6 X 1.0 This part replaces 293450274. |
| 27 |
704700162 |
Tool Kit This part replaces 704700148. |
| 29 |
715001894 |
Kit Rear Bumper |
| 31 |
704905698 |
Warning Decal This part replaces 704902777. |
| 32 |
704902778 |
Warning Decal, Luggage Rack |
| 34 |
705004977 |
LH Front Bracket |
| 36 |
705004978 |
RH Front Bracket |
| 40 |
705018526 |
Deep Black, Rear Pillar -SB This part replaces 705004981. |
