| Ref | Part Number | Description |
|---|
| 5 |
232561434 |
Elastic Stop Nut M6 |
| 8 |
XXX |
Not Available As Spare Parts |
| 11 |
234062670 |
Stainless Steel Flat Washer |
| 14 |
250100198 |
Panel Nut M6 X 1.0 This part replaces 250000048. |
| 15 |
XXX |
Not Available As Spare Parts |
| 18 |
XXX |
Not Available As Spare Parts |
| 19 |
XXX |
Not Available As Spare Parts |
| 21 |
250000215 |
Torx Screw M6 X 45 |
| 23 |
XXX |
Not Available As Spare Parts |
| 26 |
250000842 |
Stainless, Torx Screw M6 X 30 This part replaces 250000371. |
| 28 |
XXX |
Not Available As Spare Parts |
| 29 |
250100129 |
PUSH NUT - Call your local BRP dealership |
| 30 |
XXX |
Not Available As Spare Parts |
| 32 |
XXX |
Not Available As Spare Parts |
| 35 |
XXX |
Not Available As Spare Parts |
| 41 |
XXX |
Not Available As Spare Parts |
| 42 |
XXX |
Not Available As Spare Parts |
| 55 |
705008666 |
Black, LH Upper Front Mudguard This part replaces 705003058. |
| 56 |
705008667 |
Black, RH Upper Front Mudguard This part replaces 705003059. |
| 59 |
705008668 |
Black, LH Lower Mudguard This part replaces 705003601. |
| 60 |
705008669 |
Black, RH Lower Mudguard This part replaces 705003602. |
| 61 |
705008671 |
LH Upper Rear Mudguards This part replaces 705003603. |
| 62 |
705008673 |
RH Upper Rear Mudguards This part replaces 705003604. |
| 63 |
705008670 |
Black, LH Rear Lower Mudguard This part replaces 705003605. |
| 64 |
705008672 |
RH Rear Lower Black Mudguard This part replaces 705003606. |
| 76 |
XXX |
Not Available As Spare Parts |
| 85 |
XXX |
Not Available As Spare Parts |
| 86 |
XXX |
Not Available As Spare Parts |
| 97 |
XXX |
Not Available As Spare Parts |
| 98 |
706200281 |
Hardened Washer This part replaces 250200086. |
| 100 |
XXX |
Not Available As Spare Parts |
| 101 |
XXX |
Not Available As Spare Parts |
| 102 |
XXX |
Not Available As Spare Parts |
| 103 |
XXX |
Not Available As Spare Parts |
| 104 |
XXX |
Not Available As Spare Parts |
| 107 |
XXX |
Not Available As Spare Parts |
| 108 |
XXX |
Not Available As Spare Parts |
| 109 |
715002451 |
FENDER EXTENSION KIT - Call your local BRP dealership This part replaces 715001013. |
| 110 |
XXX |
Not Available As Spare Parts |
| 111 |
XXX |
Not Available As Spare Parts |
| 112 |
XXX |
Not Available As Spare Parts |
| 113 |
XXX |
Not Available As Spare Parts |
| 114 |
XXX |
Not Available As Spare Parts |
| 115 |
XXX |
Not Available As Spare Parts |
| 116 |
XXX |
Not Available As Spare Parts |
