| Ref | Part Number | Description |
|---|
| 1 |
5032118 |
HOOK, INSTRUMENT PANEL |
| 2 |
5032127 |
COVER, Side stbd. |
| 4 |
5032130 |
HOLDER, Side cover |
| 5 |
5032131 |
HOLDER, Side cover |
| 6 |
5032132 |
CUSHION, Side cover holder |
| 7 |
5032133 |
PANEL, Front |
| 8 |
5032134 |
BRACKET, Front panel |
| 9 |
5032135 |
PROTECTION, CAPOT LATÉRAL |
| 10 |
5031824 |
SCREW (6X30) |
| 11 |
5031906 |
CLIP |
| 15 |
5032301 |
BOLT |
| 16 |
5031690 |
VIS |
| 17 |
5031637 |
SCREW |
| 18 |
5032125 |
HOOK, ENGINE COVER |
| 19 |
5032126 |
LEVER, Hook rear |
| 20 |
5031821 |
BOULON (6 x 12 mm) |
| 21 |
5031833 |
WASHER (13.2X25X1.0) |
| 22 |
5031857 |
WASHER, WAVE |
| 23 |
5031894 |
BUSH |
| 25 |
5034716 |
SEAL, SIDE COVER This part replaces 5032114. |
| 26 |
5032115 |
CUSHION, SIDE COVER |
| 27 |
2032128 |
PLUG, Side cover |
| 28 |
5030120 |
CUSHION |
| 30 |
5031593 |
BUTÉE, CÂBLE CDE DISTANCE This part replaces 5030954. |
