07- Body - Side Panels
Parts (29)
| Ref | Part Number | Description |
|---|---|---|
| 1 | 5011099 | Housing & Filter A This part replaces 5006064. |
| 2 | 5011099 | Housing & Filter A This part replaces 5005953. |
| 3 | 5012363 | Filter Ay This part replaces 0502906. |
| 10c | 517303439 | Grommet |
| 10f | 250000725 | Screw M4 X 16 |
| 14 | 0351846 | HOSE, Filter to vapor separator |
| 16 | 3011450 | ATTACHE, connecteur |
| 400 | 517306759 | RH Console |
| 410 | 250000586 | Torx Truss M5 X 20 |
| 420 | 250000958 | Panel Nut M5 X 0.8 |
| 430 | 517306315 | Rope Guide |
| 440 | 210261250 | Hex. Flanged Screw M6 X 12 |
| 900 | 517306811 | Rubber Latch |
| 1000a | 517307809 | RH Side Panel This part replaces 517308573. |
| 1020 | 517306320 | RH Rear Latch |
| 1025 | 517305773 | RH Rear Latch |
| 1030 | 250000805 | Plastite Screw M4 X 10 |
| 1035 | 517307193 | White, RH Trim |
| 1068 | 517306489 | RH Side Panel Cap |
| 1070 | 517307417 | RH Central Side Panel Heat Shield |
| 1080 | 517307418 | RH Rear Side Panel Heat Shield |
| 1090 | 517307419 | RH Upper Side Panel Heat Shield |
| 1200a | 517307810 | LH Side Panel This part replaces 517308574. |
| 1220 | 517306325 | LH Rear Latch |
| 1225 | 517305774 | LH Rear Latch |
| 1230 | 250000805 | Plastite Screw M4 X 10 |
| 1235 | 517307194 | White, LH Trim |
| 1268 | 517306488 | LH Side Panel Cap |
| 1400 | 517305985 | Rear Stud |
