| Ref | Part Number | Description |
|---|
| 3 |
0307832 |
PLUG, Screw |
| 10 |
0307901 |
ROLL PIN |
| 13 |
0336842 |
CLIP, SPRING This part replaces 0603145. |
| 21 |
0326151 |
SPRING, Override |
| 22 |
0387908 |
LEVER AND PIN ASSY |
| 27 |
0318832 |
O-RING, No. 35 |
| 27 |
0325829 |
HIGH SPEED ORIFICE, No. 42 |
| 27 |
0327689 |
ORIFICE, No 67 |
| 28 |
0314906 |
CLIP |
| 32 |
0387590 |
FLOAT CHAMBER |
| 35 |
0324977 |
ORIFICE, No. 61, 20 inch transom |
| 35 |
0326856 |
HIGH SPEED ORIFICE, No. 62 |
| 35 |
0326928 |
ORIFICE PLUG (#55) |
| 35 |
0327689 |
ORIFICE, No 67 This part replaces 0325836. |
| 35 |
0327739 |
ORFICE, No 59 |
| 35 |
0327740 |
ORIFICE, No 68 |
| 37 |
0317501 |
SCREW PLUG, Orifice |
| 39 |
0325092 |
GASKET |
| 40 |
0316355 |
BUT, Carburetor mounting |
| 0387906 |
0387906 |
CARBURETOR ASSEMBLY, Middle |
| 0387907 |
0387907 |
CARBURETOR ASSEMBLY, Upper & lower |
| 0391608 |
0392574 |
CARBURETOR ASSEMBLY, Upper & lower This part replaces 0391608. |
| 0391609 |
0391609 |
CARBURETOR ASSEMBLY, Middle |
| 0391632 |
0391632 |
CARBURETOR ASSEMBLY, Middle, 20 inch transom |
| 0391633 |
0392576 |
CARBURETOR ASSEMBLY, Upper & lower This part replaces 0391633. |
