| Ref | Part Number | Description |
|---|
| 1 |
0320107 |
ATTACHE-CÂBLE, connecteur capteur de position de vilebrequin vers clapet |
| 2 |
HOSE, |
Primer to tee 7" |
| 5 |
0909678 |
JOINT TORIQUE, interrupteur d'aspiration vers support |
| 7 |
0395146 |
PLUNGER & VALVE ASSY. |
| 9 |
0398868 |
END CAP This part replaces 0328802. |
| 12 |
HOSE, |
Primer to upper carb. 7" |
| 13 |
HOSE, |
Carb. to primer 8-1/2" |
| 14 |
0329054 |
SCREW |
| 15 |
0395781 |
KNOB & DETENT ASSY This part replaces 0393835. |
| 16 |
0329670 |
NUT |
| 17 |
0325564 |
CONNECTOR, Drain hose |
| 0394009 |
0394009 |
PRIMER PUMP ASSY |
