10- Electrical System Rear View_20Y1503b
Parts (57)
| Ref | Part Number | Description |
|---|---|---|
| 16 | 205561660 | Socket Head Screw M6 X 16, Scotch Grip |
| 17 | 205851036 | Socket Head Screw M5 X 10 |
| 19 | 207142544 | Hex. Screw M4 X 25 |
| 22 | 207561644 | Hex. Flange Screw M6 X 16, Scotch Grip |
| 26 | 207581644 | Hex. Flange Screw M8 X 16, Scotch Grip |
| 35 | 224060201 | Flat Washer |
| 36 | 232041200 | Brass Hex Nut M4 DIN.934 |
| 47 | 234040200 | Brass Flat Washer DIN.433 M4 |
| 48 | 234051600 | Flat Washer M5, Stainless |
| 51 | 234082430 | Flat Washer M8 |
| 52 | 234140602 | Curved Stainless Lock Washer DIN.128A |
| 59 | 250000287 | Flange Torx Screw K40 X 16 |
| 60 | 250000348 | Torx Truss Screw M6 X 16 |
| 61 | 250000843 | Torx Truss Screw M6 X 30 This part replaces 250000398. |
| 62 | 250000405 | TORX SCREW M4 X 20 - Call your local BRP dealership |
| 63 | 250000720 | Torx Screw K50 X 16 |
| 64 | 250000725 | Screw M4 X 16 |
| 86 | 293150230 | Tuflok Plastic Rivet This part replaces 293150089. |
| 89 | 293720084 | Grommet |
| 91 | 293750001 | Tie Wrap 94 mm |
| 92 | 293750002 | Tie Wrap 142 mm |
| 119 | 293750040 | Tie-rap Mount (square - self-adhsive) |
| 120 | 293750058 | Tie Rap 2 Pièces pour Bordure |
| 136 | 414115200 | Tie-Rap 180 mm |
| 161 | 414227300 | Clip |
| 165 | 515175220 | Wrap_Tie 200 X 4.6 - Call Your Local BRP Dealership |
| 191 | 517225900 | Flat Washer |
| 200 | 705003635 | Well Rubber Nut M4 X 0.7 |
| 203 | 705601372 | Sensor Wheel |
| 211 | 706202361 | Speed Sensor This part replaces 706200560. |
| 213 | 709401318 | GPS SUPPORT, BLACK - Call your local BRP dealership |
| 238 | 710001248 | DC Outlet |
| 261 | 219800128 | Bulb |
| 264 | 710001532 | Antenna Support |
| 273 | 219704354 | Trim 1000Mm Long |
| 291 | 710002023 | Shim |
| 292 | 710002024 | Shim |
| 296 | 219704354 | Trim 1000Mm Long |
| 297 | 219400315 | WEATHERCAP - Call your local BRP dealership |
| 298 | 710002145 | Hose Support |
| 303 | XXX | Not Available As Spare Parts |
| 307 | XXX | Not Available As Spare Parts |
| 313 | 710002349 | LH Housing |
| 316 | 710002676 | IPOD INLET - Call your local BRP dealership |
| 317 | 710001406 | MP3 Audio Plug |
| 327 | 710002464 | RH Passenger Switch Housing |
| 341 | 710002740 | Antenna |
| 343 | 710002860 | Rear Support |
| 346 | 710002896 | Tie-Rap Clip |
| 387 | 710003232 | Rear Speaker |
| 389 | 710003249 | ANTENNA CABLE ASS'Y - Call your local BRP dealership |
| 476 | 232541414 | Elastic Stop Nut M4 |
| 477 | 710003861 | Retaining Ring |
| 480 | 710003997 | PROTECTOR BOOT - Call your local BRP dealership |
| 490 | 219800399 | REBUILT RADIO MODULE 5V IPOD - Call your local BRP dealership This part replaces 710004211. |
| 501 | 710004254 | GPS Protector Support |
| 511 | 710004281 | Protector |
