| Ref | Part Number | Description |
|---|
| 2 |
277001825 |
LOCK - Call your local BRP dealership |
| 3 |
277001829 |
WASHER - Call your local BRP dealership |
| 4 |
277001823 |
MOLDED LEVER - Call your local BRP dealership |
| 5 |
277001828 |
SCREW M4 X 8 - Call your local BRP dealership |
| 6 |
277001830 |
SPRING - Call your local BRP dealership |
| 7 |
204390634 |
SCREW M5 X 25 - Call your local BRP dealership |
| 8 |
204390632 |
CONTROL HANDLE - Call your local BRP dealership |
| 9 |
Not |
Available As Spare Part - Frame |
| 10 |
277000398 |
BUSHING - Call your local BRP dealership |
| 11 |
277000397 |
BUSHING - Call your local BRP dealership |
| 12 |
277001831 |
BALL BASE - Call your local BRP dealership |
| 13 |
Not |
Available As Spare Part - Shift Lever |
| 14 |
277000404 |
BLOCKING PIVOT - Call your local BRP dealership |
| 16 |
204390626 |
THROTTLE LEVER - Call your local BRP dealership |
| 19 |
Not |
Available As Spare Part - Half Case |
| 20 |
Not |
Available As Spare Part - Throttle Lever |
| 21 |
204100016 |
SCREW M5 X 20 - Call your local BRP dealership |
| 22 |
277000402 |
CAP SCREW - Call your local BRP dealership |
| 23 |
277000403 |
FRICTION INSERT - Call your local BRP dealership |
| 24 |
277001832 |
DETENT SPRING - Call your local BRP dealership |
| 25 |
277000399 |
BALL - Call your local BRP dealership |
| 26 |
Not |
Available As Spare Part - Screw M5 X 14 |
| 27 |
277001826 |
LOCK COVER - Call your local BRP dealership |
| 28 |
204390227 |
RETAINING PLATE - Call your local BRP dealership |
| 29 |
Not |
Available As Spare Part - Screw M5 X 16 |
| 37 |
Not |
Available As Spare Part - RH Water Seal |
| 39 |
Not |
Available As Spare Part - LH Water Seal |
| 40 |
204390633 |
THROTTLE HANDGRIP - Call your local BRP dealership |
| 42 |
204390630 |
RED KNOB CAP - Call your local BRP dealership |
| 43 |
204390631 |
BLACK KNOB CAP - Call your local BRP dealership |
| 45 |
277001851 |
NEUTRAL SWITCH ASS'Y - Call your local BRP dealership |
| 47 |
204390226 |
CLEVIS L26 - Call your local BRP dealership |
| 48 |
277001847 |
SCREW M3X6 - Call your local BRP dealership |
| 49 |
207151660 |
HEX. SCREW M5 X 16 - Call your local BRP dealership |
| 50 |
204390045 |
THROTTLE LINK - Call your local BRP dealership |
| 51 |
232551600 |
Hex. Elastic Nut M5 |
| 52 |
205353060 |
SCREW M5 X 30 - Call your local BRP dealership |
| 53 |
204390610 |
THROTTLE STOP - Call your local BRP dealership |
| 54 |
211200025 |
Lock Washer 1/4” |
| 55 |
207161260 |
Hex. Cap Screw M6 X 12 |
| 56 |
293750015 |
TIE RAP MOUNT - Call your local BRP dealership |
| 57 |
293750001 |
Tie Wrap 94 mm |
| 60 |
277000504 |
CABLE SUPPORT - Call your local BRP dealership |
| 61 |
293150026 |
RIVET_POP 1/8 - Call your local BRP dealership |
| 350 |
XXX |
Not Available As Spare Parts |
| 355 |
XXX |
Not Available As Spare Parts |
| 360 |
XXX |
Not Available As Spare Parts |
| 370 |
XXX |
Not Available As Spare Parts |
| 520 |
XXX |
Not Available As Spare Parts |
| 530 |
XXX |
Not Available As Spare Parts |
| 550 |
XXX |
Not Available As Spare Parts |
| 560 |
XXX |
Not Available As Spare Parts |
| 570 |
XXX |
Not Available As Spare Parts |
