| Ref | Part Number | Description |
|---|
| 10 |
0435957 |
DIAPHRAGM |
| 10 |
515178227 |
Multifunction Gauge Full Size Color |
| 11 |
0436195 |
ENSEMBLE THERMOSTAT |
| 12 |
0329830 |
GASKET, Cover |
| 13 |
0306049 |
SCREW |
| 15 |
0325211 |
GASKET |
| 16 |
0437506 |
COVER & PLUG Assy, Water passage |
| 18 |
0432921 |
SPARK PLUG, Champion, L78C |
| 18 |
0432981 |
SP PLG QL78C |
| 18 |
0437929 |
BOUGIE, Champion, QL78YC |
| 19 |
0316355 |
BUT, Carburetor mounting This part replaces 0315204. |
| 20 |
0335359 |
GASKET, Cylinder head |
| 22 |
0339540 |
CYLINDER HEAD |
| 23 |
0584589 |
TEMPERATURE SWITCH |
| 26 |
0302288 |
BOLT |
| 29 |
0343141 |
COVER, Thermostat This part replaces 0339207. |
| 31 |
HOSE, |
Indicator, 18 3/4 in. (480mm) |
| 33 |
0326023 |
LIFT BRACKET |
| 34 |
0322323 |
SCREW |
| 37 |
0342421 |
SPRING |
| 60 |
515178965 |
Gauge Support |
| 70 |
250000725 |
Screw M4 X 16 |
| 600 |
710006855 |
Ignition Switch |
| 610 |
278004274 |
Specialized Nut |
| 620 |
515179476 |
Grey, LYNX DESS Key |
| 800 |
515178645 |
Heated Visor Wiring Harness |
| 810 |
572103300 |
Cap |
| 1000 |
219400510 |
USB Outlet |
| 1010 |
515178190 |
Harness |
| 1040 |
515178153 |
Extension Harness |
| 2400 |
515178196 |
LH Switch Housing |
| 2410 |
515177147 |
Housing Plate |
| 2420 |
250000671 |
Torx Screw |
| 2470 |
415130141 |
Sleeve |
| 2480 |
415130141 |
Sleeve |
| 2600 |
515177931 |
Emergency Stop Switch |
| 2610 |
515177310 |
Emergency Stop Switch Support |
| 2620 |
250000263 |
Torx Screw #8-18 |
| 3250 |
515178501 |
Rocket Switch |
| 5000 |
420464172 |
ECM Module |
| 5020 |
512061397 |
Module Support |
| 0437341 |
0437341 |
CYLINDER & C'CASE Assy |
