06-2_EXHAUST ADAPTER & MUFFLER
Parts (16)
| Ref | Part Number | Description |
|---|---|---|
| NS | 0356614 | HOSE, Back pressure |
| 1 | 5010126 | EXHAUST ADAPTER |
| 16 | 358382 | Pipe |
| 17 | 0356006 | SEAL |
| 19 | 0359180 | HOSE, Idle relief |
| 21 | 5009486 | HOSE & TUBE KIT |
| 24 | 0352335 | COLLIER, 33,1 mm |
| 28 | 5009387 | RUBBER MOUNT ASSEMBLY, Upper |
| 29 | 0330929 | PLATE, Upper mount |
| 30 | 0356263 | SCREW, Upper mount plate |
| 36 | 3011450 | ATTACHE, connecteur |
| 38 | 0358936 | SEAL, Exhaust adapter to |
| 40 | 0349557 | MOUNT |
| 41 | 5009783 | MUFFLER ASSEMBLY |
| 44 | 0361699 | GROMMET |
| 46 | 0358631 | GOMMET & INSERT, Overboard indicator |
