| Ref | Part Number | Description |
|---|
| 10 |
710003412 |
Brake Light Switch Ass'y |
| 15 |
707000995 |
Pressure And Temperature Sensor |
| 20 |
710001379 |
Brake Pressure Switch Ass'y |
| 25 |
207662554 |
Hex. Flange Screw M6 X 25 |
| 30 |
293150150 |
Pop Rivet |
| 35 |
250100198 |
Panel Nut M6 X 1.0 |
| 40 |
293750009 |
Tie-Rap 173 mm |
| 45 |
707000586 |
Foam Filter |
| 50 |
710002899 |
Clip Tie-Rap |
| 60 |
293750002 |
Tie Wrap 142 mm |
| 1150 |
710004916 |
Dess Module |
| 1152 |
293750009 |
Tie-Rap 173 mm |
| 1153 |
710004308 |
Wire Support |
| 1154 |
210261050 |
Hex. Forming Screw M6 X 10 |
| 1155 |
210262050 |
Hexagonal Head Screw |
| 1156 |
234062410 |
Flat Washer 6 mm |
| 1160 |
293830091 |
Rubber Bumper |
| 2000 |
710006399 |
Starter Cable Ass'y |
| 2005 |
207582044 |
Hex. Flange Screw M8 X 20, Scotch Grip |
| 2020 |
207581244 |
Hex. Flange Screw M8 X 12, Scotch Grip |
| 2021 |
234481608 |
Serrated Lock Washer 8 mm |
| 2160 |
234061600 |
Stainless Flat Washer M6 |
| 2161 |
232561414 |
Elastic Stop Nut M6 |
| 2170 |
234161601 |
Lock Washer Helical M6 |
| 2171 |
232061600 |
Hex. Nut M6 |
| 2250 |
710005026 |
Pos Cable |
| 2260 |
232061600 |
Hex. Nut M6 |
| 2261 |
234161601 |
Lock Washer Helical M6 |
| 2270 |
293150173 |
Rivet 6,4 mm |
| 2280 |
293150173 |
Rivet 6,4 mm |
| 4042 |
710001222 |
Lock |
| 4044 |
390402400 |
Pop Rivet 3/16" |
| 4045 |
270000141 |
Clip |
| 4050 |
293750008 |
Tie Wrap 368 mm |
| 4052 |
293150230 |
Tuflok Plastic Rivet |
| 4065 |
293750083 |
Cable Support |
| 4066 |
293750058 |
Tie Rap 2 Pièces pour Bordure |
| 4067 |
293750009 |
Tie-Rap 173 mm |
| 4068 |
710004947 |
Tie Rap |
| 4069 |
293750063 |
Clip Tie-Rap |
| 4070 |
709000401 |
Rubber Pad |
| 4074 |
710004613 |
Support |
| 4077 |
710004669 |
Wire Support |
| 4080 |
414115200 |
Tie-Rap 180 mm |
| 4090 |
710004794 |
Harness Holder |
| 4091 |
414115200 |
Tie-Rap 180 mm |
| 4095 |
293150230 |
Tuflok Plastic Rivet |
| 4110 |
293750008 |
Tie Wrap 368 mm |
| 4124 |
293750009 |
Tie-Rap 173 mm |
| 4125 |
293750009 |
Tie-Rap 173 mm |
| 4200 |
710004931 |
Harness Holder |
| 4210 |
414745900 |
Tuflock Phillips Plastic Screw |
| 4220 |
710004424 |
Tie Rap |
| 4221 |
414115200 |
Tie-Rap 180 mm |
| 4222 |
414115200 |
Tie-Rap 180 mm |
| 4225 |
414745900 |
Tuflock Phillips Plastic Screw |
| 4230 |
710004424 |
Tie Rap |
| 4235 |
414745900 |
Tuflock Phillips Plastic Screw |
| 4350 |
709402446 |
Wiring Harness Support This part replaces 709401619. |
| 4351 |
250000742 |
Torx Screw M5 X 14 |
| 4360 |
710004472 |
Fuse Holder Support |
| 4361 |
210261250 |
Hex. Flange Screw M6 X 12 |
| 4370 |
710003077 |
RH/LH Fuse Box Decal |
| 4380 |
710004299 |
Cable Support |
| 4800 |
710006428 |
Tail Harness |
| 4810 |
710004456 |
Connector With Cap |
| 5001 |
234181601 |
Lock Washer 8 mm, Stainless |
| 5002 |
232081414 |
Hex. Nut M8 |
| 5400 |
710006436 |
Fuel Tank Cable |
| 5405 |
207382060 |
Hex. Screw M8 X 20, Scotch Grip |
| 5410 |
250200041 |
Lock Washer Serrated M6 |
| 5415 |
234481608 |
Serrated Lock Washer 8 mm |
| 5420 |
250200111 |
Washer |
| 8400 |
710008091 |
LH Multi-Function Switch This part replaces 710006576. |
| 8500 |
710004583 |
RH Switch Housing |
| 8501 |
250000494 |
Socket Screw, M4 X 16 Scotch Grip |
| 8502 |
710004231 |
Braided Sleeve |
| 8503 |
710004231 |
Braided Sleeve |
| 8505 |
293750001 |
Tie Wrap 94 mm |
| 8506 |
293750074 |
Tie Rap |
| 8520 |
709401804 |
Wire Guide |
| 8521 |
250000453 |
Torx Cutting Screw, M4 X 10 |
| 8530 |
709401054 |
Handle Grip |
| 8531 |
250000453 |
Torx Cutting Screw, M4 X 10 |
| 8540 |
709401055 |
Throttle Handle Grip |
| 8541 |
205042594 |
Socket Screw, M4 X 25 |
| 8542 |
234040600 |
Flat Washer 4 mm |
| 8550 |
709401801 |
Bushing |
| 8560 |
709401937 |
Spring |
