| Ref | Part Number | Description |
|---|
| 10 |
715002374 |
Protective Plate Kit |
| 20 |
207662054 |
Hex. Flange Screw M6 X 20 |
| 25 |
207762044 |
Carriage Bolt M6 X 20 |
| 30 |
233261434 |
Flange Elastic Nut M6 |
| 35 |
233201434 |
Hex. Flange Elastic Nut M10 |
| 36 |
233261434 |
Flange Elastic Nut M6 |
| 40 |
705006220 |
Front Bumper Center Support |
| 50 |
207682044 |
Hex. Flange Screw M8 X 20 |
| 51 |
207582044 |
Hex. Flange Screw M8 X 20, Scotch Grip |
| 55 |
207582544 |
Hex. Flange Screw M8 X 25, Scotch Grip |
| 60 |
233281434 |
Hex. Flange Elastic Nut M8 |
| 65 |
233281464 |
Elastic Flange Nut M8 |
| 70a |
232862412 |
Square Nut M6 |
| 80 |
705011542 |
RH Structural Footboard |
| 90 |
207763554 |
Carriage Bolt M6 X 35 |
| 100 |
234062410 |
Flat Washer 6 mm |
| 110 |
705005978 |
LH Footboard |
| 120 |
705005977 |
RH Footboard |
| 121 |
250000720 |
Torx Screw K50 X 16 |
| 125 |
705004352 |
LH Footrest |
| 126 |
705005395 |
RH Footrest |
| 130 |
207661654 |
Hex. Flange Screw M6 X 16 |
| 135 |
224061201 |
Flat Washer |
| 140 |
250100198 |
Panel Nut M6 X 1.0 This part replaces 250000957. |
| 150 |
705006134 |
LH Air Deflector |
| 160 |
705006135 |
RH Air Deflector |
| 170 |
715006101 |
Console Support Ass'y This part replaces 715003984. |
| 180 |
293830005 |
Rubber Bumper |
| 185 |
705006819 |
Coupling Nut, Large |
| 190 |
705015693 |
Black, Footrest This part replaces 705011610. |
| 195 |
705006818 |
Coupling Nut, Short |
| 200 |
715004085 |
Indicator |
| 205 |
233281434 |
Hex. Flange Elastic Nut M8 |
| 215 |
206285044 |
Socket Set Screw M8 x 50 |
| 220 |
207563034 |
Hex. Flange Screw M6 X 30, Scotch Grip |
| 230 |
224061201 |
Flat Washer |
| 250 |
705012822 |
Fascia |
| 270 |
715006048 |
Sunburst Yellow, RH Front Fender |
| 280 |
705016893 |
Front Bumper Support This part replaces 705009253. |
| 290 |
705004565 |
Lower Fender Support |
| 310 |
715001852 |
Luggage Rack Kit |
| 320 |
705016640 |
Sectional Bent Tube This part replaces 705005469. |
| 330 |
705016092 |
Bent Sectional Tube This part replaces 705005470. |
| 335 |
210261040 |
Hex. Flange Screw M6 X 10 |
| 340 |
705007140 |
LH Inner Fender Bracket |
| 370 |
250000646 |
Black, Torx Screw M6 X 35 |
| 375 |
293150104 |
Pop Rivet 3/16" |
| 380 |
517124300 |
Washer |
| 390 |
250100199 |
Insert Half Hex Body M6 x 1.0 |
| 400 |
207561644 |
Hex. Flange Screw M6 X 16, Scotch Grip |
| 420 |
250000886 |
Torx Screw M8 X 30 |
| 430 |
207183054 |
Hex. Cap Screw M8 X 30 |
| 440 |
234081670 |
Stainless Steel Flat Washer 8 mm |
| 460 |
517302785 |
Edge Clip |
| 470 |
207551634 |
Hex. Flange Screw, Scotch Grip |
| 491 |
707002456 |
Heat Shield |
| 492 |
707002457 |
Heat Shield |
| 493 |
707002458 |
Heat Shield |
| 494 |
707002459 |
Heat Shield |
| 495 |
707002460 |
Heat Shield |
| 496 |
707002461 |
Heat Shield |
| 497 |
707002462 |
Heat Shield |
| 498 |
707002463 |
Heat Shield |
| 499 |
707002464 |
Heat Shield |
| 510 |
705006643 |
LH Rear Facia |
| 511 |
707002103 |
Heat Shield |
| 512 |
707002107 |
Heat Shield |
| 513 |
707002293 |
Heat Shield |
| 514 |
707002465 |
Heat Shield |
| 520 |
705006650 |
RH Rear Facia |
| 530 |
705011221 |
Red Reflector |
| 550 |
705007277 |
LH Support |
| 560 |
705007278 |
RH Support |
| 570 |
732610072 |
Push Nut |
| 580 |
250000841 |
Hex Flange Screw M6 X 25 |
| 585 |
234062670 |
Stainless Steel Flat Washer |
| 590 |
250000722 |
Torx Screw M6 X 20 |
| 595 |
207661654 |
Hex. Flange Screw M6 X 16 |
| 600 |
705006299 |
Front Guard Plate |
| 610 |
205003044 |
Socket Screw M10 x 30 |
| 640 |
705004497 |
Ring |
| 661 |
707002467 |
Heat Shield |
| 675 |
250000723 |
Phillips Screw K40 X 16 |
| 680 |
715007008 |
Deflector_Body Panel Kit This part replaces 705004147. |
| 690 |
705003444 |
Engine Cover |
| 700 |
705006373 |
Gage Support |
| 710 |
715005837 |
Dash Kit |
| 720 |
705003264 |
Grommet |
| 730 |
705011462 |
RH Rear Inner Fender |
| 740 |
705011463 |
RH Front Inner Fender |
| 750 |
705013111 |
LH Rear Inner Fender |
| 760 |
705017001 |
LH Front Wheel Arch Protector This part replaces 705011465. |
| 770 |
293150230 |
Tuflok Plastic Rivet |
| 780 |
293250242 |
Rubber Cover |
| 822a |
207782044 |
Carriage Bolt, M8 X 20 |
| 822b |
233281434 |
Hex. Flange Elastic Nut M8 |
| 822c |
250000535 |
Torx Screw M8 X 55 |
| 822d |
233281464 |
Elastic Flange Nut M8 |
| 835a |
250000842 |
Stainless, Torx Screw M6 X 30 |
| 835b |
207762044 |
Carriage Bolt M6 X 20 |
| 835c |
233261434 |
Flange Elastic Nut M6 |
| 835d |
233281434 |
Hex. Flange Elastic Nut M8 |
| 835e |
705005094 |
LH Bracket |
| 835f |
705005095 |
RH Bracket |
| 870 |
705008164 |
LH Rear Bracket |
| 880 |
705008165 |
RH Rear Bracket |
| 930 |
715001897 |
LH Extension Panel |
| 940 |
705004348 |
RH Extension Panel |
| 960 |
705006870 |
Heat Shield |
| 970 |
705006871 |
Heat Shield |
| 995 |
207662034 |
Hex. Flange Screw M6 X 20 |
| 1005 |
207664536 |
Hex. Flange Screw M6 X 45 |
| 1010 |
705007948 |
Seat Holder |
| 1030 |
207562054 |
Hex. Flange Screw S.Grip M6 X 20 |
| 1035 |
705008438 |
Heat Shield |
| 1040 |
708200462 |
Rod Cap |
| 1050 |
705006988 |
LH Mud Guard |
| 1051 |
705006989 |
RH Mud Guard |
| 1052 |
705003918 |
LH Rear Mudguard |
| 1053 |
705003920 |
RH Rear Mudguard |
| 1054 |
705004888 |
LH Mudgard Cap |
| 1055 |
705004889 |
RH Mudgard Cap |
| 1056 |
732610072 |
Push Nut |
