| Ref | Part Number | Description |
|---|
| 1 |
420219736 |
Crankshaft This part replaces 420219735. |
| 2 |
420246570 |
Woodruff Key 4 X 5 |
| 4 |
420641475 |
Connecting Rod Screw M9 X 1 This part replaces 420641477. |
| 5 |
420233726 |
Plain Bearing |
| 7 |
420296774 |
Piston Ring Set This part replaces 420685244. |
| 8 |
420216351 |
Piston Pin This part replaces 420216352. |
| 9 |
420245436 |
Piston Circlip |
| 10 |
420630211 |
Gasket Aramid This part replaces 420630210. |
| 11 |
420413111 |
Cylinder Front This part replaces 420623566. |
| 12 |
420413116 |
Cylinder Rear This part replaces 420623568. |
| 13 |
420929650 |
Drive Pin 5 X 10 |
