| Ref | Part Number | Description |
|---|
| 33 |
278000999 |
Wire Seal |
| 99 |
278000992 |
Open Barrel |
| 101 |
278001392 |
Open Barrel Terminal |
| 110 |
278000631 |
Male Terminal |
| 112 |
278000632 |
Female Terminal |
| 113 |
278001661 |
FEMALE TERMINAL - Call your local BRP dealership |
| 116 |
278000635 |
Female Housing, 4 Circuits |
| 120 |
409207300 |
Female Connector, 2 Circuits |
| 121 |
278002375 |
CONNECTOR_FEMALE 3 CAVITIES - Call your local BRP dealership This part replaces 409207400. |
| 122 |
278000739 |
Male Connector, 4 Circuits |
| 123 |
710001540 |
CONNECTOR_MALE 6 CAVITIES - Call your local BRP dealership This part replaces 278000736. |
| 128 |
278000636 |
Female Wedge, 4 Circuits |
| 132 |
409207500 |
Male Lock, 2 Circuits |
| 133 |
409207200 |
Female Lock |
| 134 |
278000738 |
Male Lock, 4 Circuits |
| 135 |
278000737 |
MALE LOCK, 6 CIRCUITS - Call your local BRP dealership |
| 138 |
293000052 |
Sealing Cap |
| 196 |
293750002 |
Tie Wrap 142 mm |
| 202 |
278001114 |
Female Terminal |
| 203 |
278001113 |
Male Connector, 2 Circuits |
| 229 |
278000223 |
Female Terminal |
| 238 |
278000273 |
Male Housing, 3 Circuits |
| 242 |
278000218 |
Wire Seal |
| 243 |
710000048 |
Wire Seal |
| 244 |
278000216 |
Wire Seal |
| 257 |
219704398 |
Was 409901600 Tubing 19mm |
| 260 |
219704423 |
Was 515175319 Tubing 22 mm |
| 320 |
409015800 |
Male Connector, 12 Circuits |
| 330 |
409015600 |
MALE LOCK, 12 CIRCUITS - Call your local BRP dealership |
| 388 |
278001750 |
FEMALE TERMINAL - Call your local BRP dealership |
| 391 |
278001751 |
MALE HOUSING, 41 CIRCUITS - Call your local BRP dealership |
| 398 |
278001308 |
MALE CONNECTOR, 4 CIRCUITS - Call your local BRP dealership |
| 437 |
515175886 |
SEAL - Call your local BRP dealership |
| 438 |
515175883 |
Latch |
| 439 |
515175884 |
LOCK - Call your local BRP dealership |
| 440 |
515175885 |
COVER - Call your local BRP dealership |
| 525 |
710000482 |
SHRINK TUBING - Call your local BRP dealership |
| 541 |
219704425 |
Tubing 6 Mm 3000Mm Long |
| 542 |
219704399 |
Was 409901700 Tubing (9 mm) |
| 543 |
409902000 |
Tubing 12 mm |
| 545 |
219704408 |
Tubing 16 Mm 1000Mm Long |
| 668 |
710000744 |
Little Fuse, 10 Amperes |
| 669 |
710000745 |
Little Fuse, 15 Ampere |
| 671 |
710000747 |
Little Fuse, 30 Amperes |
| 675 |
415129856 |
Fuse Box Base Ass´y This part replaces 710000660. |
| 684 |
710000781 |
Fuse Puller |
| 690 |
710000890 |
Female Terminal |
| 702 |
710000836 |
Female Terminal |
| 703 |
710000837 |
Female Terminal |
| 706 |
710000840 |
Cap |
| 732 |
710000877 |
Female Terminal |
| 734 |
710000879 |
Female Housing, 3 Circuits |
| 735 |
710000880 |
Housing, 3 Circuits |
| 736 |
710000881 |
Seal |
| 737 |
710000882 |
Cap |
| 751 |
710000918 |
Female Terminal |
| 767 |
278002165 |
Bus Bar |
| 768 |
278002165 |
Bus Bar |
| 769 |
278002165 |
Bus Bar |
| 770 |
710001008 |
Little Fuse, 3 AMP |
| 773 |
710001026 |
Fuse Cover |
| 778 |
278002165 |
Bus Bar |
| 801 |
278002188 |
RESISTANCE 500 OHMS - Call your local BRP dealership |
| 949 |
278002285 |
Fuse Box Ass'y |
| 950 |
278002286 |
Fuse Box Cover |
| 953 |
278002306 |
DIODE CAP - Call your local BRP dealership |
| 2023 |
278002171 |
FUSE DECAL - Call your local BRP dealership |
