| Ref | Part Number | Description |
|---|
| 2 |
204071433 |
Fluted Knob |
| 3 |
204100094 |
SOCKET HEAD SCREW 3/8-16 X 1-1/2 - Call your local BRP dealership |
| 4 |
204071845 |
STRAP EYE - Call your local BRP dealership |
| 5 |
204130057 |
RIVET 5/32 X 3/8 SS - Call your local BRP dealership |
| 6 |
204071846 |
BIMINI BRACKET - Call your local BRP dealership |
| 7 |
204071847 |
Knob, Black |
| 8 |
204130058 |
RIVET 3/16 X 1/2 SS - Call your local BRP dealership |
| 9 |
204072012 |
Joint 1/2" |
| 10 |
204100190 |
Socket Screw 1/2-13 X 1-1/2" |
| 11 |
204100131 |
LOCK NUT 1/2? - Call your local BRP dealership |
| 12 |
204100132 |
FENDER WASHER - Call your local BRP dealership |
| 13 |
204100152 |
Threaded Stud |
| 14 |
204130105 |
Gasket |
| 15 |
295100386 |
SKI MIRROR - Call your local BRP dealership This part replaces 204071420. |
| 16 |
204100129 |
PHILLIPS SCREW 10-32 X 1? - Call your local BRP dealership |
| 17 |
204072648 |
Tower Support |
| 18 |
293800005 |
Loctite 271, 10 ml |
| 19 |
293800060 |
Loctite 243, 10 ml |
| 20 |
204072099 |
SPACER WITH NUT - Call your local BRP dealership |
| 21 |
204071830 |
TOWER STRAP - Call your local BRP dealership |
| 22 |
204901340 |
WARNING DECAL, TOWER - Call your local BRP dealership |
| 24 |
293150039 |
Pop Rivet 3/16" |
| 25 |
204071842 |
FRONT STRAP - Call your local BRP dealership |
| 26 |
204072690 |
Bimini Top Boot |
