| Ref | Part Number | Description |
|---|
| 10a |
503196283 |
Black, Slider Shoe 137'' |
| 10b |
208562531 |
Phillips Screw M6 X 25 |
| 10c |
232561414 |
Elastic Stop Nut M6 |
| 10d |
503196873 |
Rail Protector |
| 10f |
250200140 |
Washer |
| 10g |
207652544 |
Hex. Flange Screw M5 X 25 |
| 10h |
233251434 |
Flange Elastic Nut M5 This part replaces 233251414. |
| 10j |
503190576 |
Rubber Stopper |
| 10k |
503191273 |
Washer |
| 10m |
293150256 |
Rivet Ornit 4.8 X 27.5 |
| 10n1 |
503195475 |
Deep Black, Rail Suspension 137 |
| 10n2 |
503196477 |
Deep Black, LH Rail Reinforcement |
| 10n3 |
503192494 |
Washer |
| 10n4 |
207183054 |
Hex. Cap Screw M8 X 30 |
| 10n5 |
233281466 |
Elastic Flange Nut M8 |
| 10n6 |
250000945 |
Hex. Flange Screw M6 X 25 |
| 10n7 |
233261466 |
Hex. Flange Elastic Nut M6 |
| 15a |
503196283 |
Black, Slider Shoe 137'' |
| 15b |
208562531 |
Phillips Screw M6 X 25 |
| 15c |
232561414 |
Elastic Stop Nut M6 |
| 15d |
503196873 |
Rail Protector |
| 15f |
250200140 |
Washer |
| 15g |
207652544 |
Hex. Flange Screw M5 X 25 |
| 15h |
233251434 |
Flange Elastic Nut M5 This part replaces 233251414. |
| 15j |
503190576 |
Rubber Stopper |
| 15k |
503191273 |
Washer |
| 15m |
293150256 |
Rivet Ornit 4.8 X 27.5 |
| 15n1 |
503195475 |
Deep Black, Rail Suspension 137 |
| 15n2 |
503196478 |
Deep Black, RH Rail Reinforcement |
| 15n3 |
503192494 |
Washer |
| 15n4 |
207183054 |
Hex. Cap Screw M8 X 30 |
| 15n5 |
233281466 |
Elastic Flange Nut M8 |
| 15n6 |
250000945 |
Hex. Flange Screw M6 X 25 |
| 15n7 |
233261466 |
Hex. Flange Elastic Nut M6 |
| 18 |
503196016 |
Adjustment Cam |
| 310 |
503193717 |
Rubber Stopper Ass'y |
| 310b |
572084800 |
Reinforcement Stopper |
| 315 |
503191273 |
Washer |
| 316 |
293150256 |
Rivet Ornit 4.8 X 27.5 |
| 320 |
503192750 |
Rubber Stopper |
| 325 |
503191273 |
Washer |
| 326 |
293150256 |
Rivet Ornit 4.8 X 27.5 |
| 440a |
503190396 |
Ball Bearing |
| 440b |
415129371 |
Retaining Ring |
| 441 |
503193894 |
Casted Support |
| 442 |
503190434 |
Labyrinth Seal |
| 443 |
503191820 |
Wheel Cup M6 |
| 444 |
250000944 |
Hex. Flange Screw M6 X 70 |
| 445 |
233261466 |
Hex. Flange Elastic Nut M6 |
| 446 |
250000945 |
Hex. Flange Screw M6 X 25 |
| 447 |
233261466 |
Hex. Flange Elastic Nut M6 |
| 448 |
503195878 |
Black, Wheel Cap |
| 450a |
503190396 |
Ball Bearing |
| 450b |
415129371 |
Retaining Ring |
| 451 |
503193894 |
Casted Support |
| 452 |
503190434 |
Labyrinth Seal |
| 453 |
503191820 |
Wheel Cup M6 |
| 454 |
250000944 |
Hex. Flange Screw M6 X 70 |
| 455 |
233261466 |
Hex. Flange Elastic Nut M6 |
| 456 |
250000945 |
Hex. Flange Screw M6 X 25 |
| 457 |
233261466 |
Hex. Flange Elastic Nut M6 |
| 458 |
503195878 |
Black, Wheel Cap |
| 460a |
503190396 |
Ball Bearing |
| 460b |
415129371 |
Retaining Ring |
| 461 |
503193894 |
Casted Support |
| 462 |
503190434 |
Labyrinth Seal |
| 463 |
503191820 |
Wheel Cup M6 |
| 464 |
250000944 |
Hex. Flange Screw M6 X 70 |
| 465 |
233261466 |
Hex. Flange Elastic Nut M6 |
| 466 |
207663056 |
Hex. Flange Screw M6 X 1.0 X 30 |
| 467 |
233261466 |
Hex. Flange Elastic Nut M6 |
| 468 |
503195878 |
Black, Wheel Cap |
| 600a |
503190396 |
Ball Bearing |
| 600b |
415129371 |
Retaining Ring |
| 610 |
503190429 |
Rear Axle |
| 620 |
503197435 |
Spacer |
| 660 |
503196753 |
Rear Wheel Support |
| 670a |
503190396 |
Ball Bearing |
| 670b |
415129371 |
Retaining Ring |
| 680 |
503190682 |
Labyrinth Seal |
| 710 |
503191910 |
Washer |
| 720 |
234201474 |
Conical Spring Washer 10 mm |
| 730 |
250000817 |
Hex Screw With Nilon Patch, M10 X 35 |
| 800 |
861805547 |
Spring Support Kit |
| 810 |
503196210 |
Bushing |
| 830 |
205082554 |
Socket Screw M8 X 25 |
| 840 |
233281466 |
Elastic Flange Nut M8 |
| 900 |
503192583 |
Tensioner |
| 910 |
503193250 |
Spacer |
| 920 |
230100054 |
Hex Screw M10 x 100 |
| 930 |
233601466 |
Elastic Locking Nut M10 |
| 940 |
207063054 |
Hex. Cap Screw M6 X 30 |
| 950 |
233261466 |
Hex. Flange Elastic Nut M6 |
| 1000 |
503196930 |
Axle Stopper Strap |
| 1010 |
503196943 |
Spacer |
| 1020 |
503192494 |
Washer |
| 1030 |
503192440 |
Bolt M8 X 248mm |
| 1040 |
233281466 |
Elastic Flange Nut M8 |
| 1090 |
503195954 |
Pivot Axle |
| 1100 |
503195825 |
Spacer |
| 1110 |
503192494 |
Washer |
| 1120 |
503192440 |
Bolt M8 X 248mm |
| 1130 |
233281466 |
Elastic Flange Nut M8 |
| 1140 |
503191260 |
Axle Strap |
| 1150 |
503192496 |
Washer |
| 1160 |
205503554 |
Socket Head Screw M10 X 35 |
| 1240 |
503196930 |
Axle Stopper Strap |
| 1250 |
503192494 |
Washer |
| 1260 |
503192440 |
Bolt M8 X 248mm |
| 1270 |
233281466 |
Elastic Flange Nut M8 |
