| Ref | Part Number | Description |
|---|
| 4 |
0318832 |
O-RING, No. 35 |
| 14 |
0336842 |
CLIP, SPRING |
| 15 |
0338878 |
GASKET |
| 18 |
0330286 |
LINK, Cam follower |
| 19 |
0323410 |
NOZZLE, High speed |
| 20 |
0319008 |
GROMMET, Cable, lower motor cover |
| 23 |
0203949 |
E RING LINK |
| 27 |
0330881 |
FLOAT CHAMBER |
| 35 |
0326225 |
LEVER, Choke knob |
| 36 |
0324696 |
LINK, Lever to valve |
| 37 |
0326229 |
LINK, Choke lever |
| 38 |
0326224 |
SHAFT, Choke & fuel shut off |
| 39 |
0336012 |
BASE, Air silencer |
| 40 |
0336036 |
AIR SILENCER |
| 42 |
0336186 |
KNOB, Choke |
| 43 |
0328742 |
NUT |
| 44 |
0323452 |
GASKET |
| 45 |
0333011 |
PLUG |
| 46 |
0336174 |
GROMMET, Choke knob |
| 47 |
0439070 |
CARBURETOR REPAIR KIT This part replaces 0398451. |
| 0434069 |
0434069 |
CARBURETOR ASSY. |
| 0435131 |
0435131 |
CARBURETOR ASSY. |
| 0435326 |
0435326 |
CARBURETOR ASSY. |
