TOP MOUNT CONTROL KIT 9-1/2 HP
Parts (12)
| Ref | Part Number | Description |
|---|---|---|
| 1 | 0171805 | STARTER PULLEY ASSEMBLY |
| 2 | 0305618 | SCREW |
| 3 | 0121487 | PULLEY |
| 6 | 0121504 | HANDLE, Throttle control |
| 7 | 0312862 | ROLL PIN, Handle to shaft |
| 8 | 0121508 | WASHER, Friction |
| 9 | 0319518 | BUSHING This part replaces 0121507. |
| 10 | 0171812 | BRACKET ASSEMBLY |
| 11 | 0171811 | SHAFT AND GEAR ASSY |
| 12 | 0300346 | GROOVE PIN, Gear to shaft |
| 14 | 0305234 | BOW WASHER |
| 0171796 | 0171796 | TOP MOUNT ACCESSORY KIT, 9-1/2 h.p. |
