07- Body - Hood Section and WindShield - Package Protk
Parts (64)
| Ref | Part Number | Description |
|---|---|---|
| 1 | 0383324 | CABLE ASSEMBLY, Motor |
| 7 | 0312691 | SCREW, Cash pannel |
| 8 | 0386947 | IGNITION SWITCH This part replaces 0383465. |
| 10 | 517306816 | Center Hood |
| 11 | 250000528 | Torx Screw M5 X 20 |
| 12 | 250000958 | Panel Nut M5 X 0.8 |
| 12 | KEY, | Ignition |
| 13 | 0975257 | SWITCH ASSEMBLLY |
| 13 | 517307086 | RH Front Hood |
| 14 | 250000528 | Torx Screw M5 X 20 |
| 15 | 0900696 | WASHER |
| 15 | 250000958 | Panel Nut M5 X 0.8 |
| 16 | 517307087 | LH Front Hood |
| 17 | 517306684 | Hood Grill |
| 18 | 0383351 | LEAD ASSEBMBLY,Ignition to choke switch |
| 20 | 250000528 | Torx Screw M5 X 20 |
| 21 | 0307911 | SCREW |
| 23 | 0383328 | CABLE ASSY., Instrument |
| 29 | 0385407 | BATTERY TERMINAL KIT This part replaces 0277708. |
| 30 | 250000958 | Panel Nut M5 X 0.8 |
| 31 | 0385407 | BATTERY TERMINAL KIT This part replaces 0277709. |
| 100 | 517307222 | RH Upper Side Panel |
| 105 | 517308487 | RH Upper Side Panel Foam |
| 110 | 250000725 | Screw M4 X 16 |
| 120 | 250000528 | Torx Screw M5 X 20 |
| 130 | 250000958 | Panel Nut M5 X 0.8 |
| 150 | 517306069 | LH Upper Side Panel |
| 155 | 517308488 | LH Upper Side Panel Foam |
| 160 | 250000725 | Screw M4 X 16 |
| 170 | 250000528 | Torx Screw M5 X 20 |
| 180 | 250000958 | Panel Nut M5 X 0.8 |
| 200 | 517307341 | Rear Console |
| 210 | 250000958 | Panel Nut M5 X 0.8 |
| 220 | 250000587 | Torx Screw M5 X 26 |
| 230 | 250000587 | Torx Screw M5 X 26 |
| 240 | 517306398 | Foam Console |
| 245 | 517304518 | Console Nut |
| 250 | 732610072 | Push Nut |
| 360 | 517306808 | Switch Hole Cap |
| 500 | 517306918 | RH Cover Plate |
| 510 | 517306919 | LH Cover Plate |
| 600 | 517307441 | Gauge Support |
| 800b | 517306183 | Deep Black, Windshield Support |
| 800c | 732610072 | Push Nut |
| 800d | 517306897 | RH Upper Air Deflector |
| 800f | 517306896 | LH Upper Air Deflector |
| 800g | 250000889 | Screw M4 X 16 |
| 800h | 250200024 | Rubber Washer 5 mm |
| 810 | 517303756 | Grommet |
| 2200k | 250000742 | Torx Screw M5 X 14 |
| 2200m | 250200024 | Rubber Washer 5 mm |
| 2200n | 250001131 | Torx Truss PT K40 x 12 |
| 2200r | 232551414 | Elastic Stop Nut M5 |
| 2200u | 250000732 | Torx Screw Nylon |
| 2400a | 415130081 | Bulb |
| 2810 | 517307161 | Grommet |
| 3010 | 517307161 | Grommet |
| 3200b | 517305779 | Latch |
| 3200c | 732610072 | Push Nut |
| 3400b | 517305157 | Seal Joint |
| 3800 | 517306824 | Black, Head Lamp Bezel |
| 3810 | 250000528 | Torx Screw M5 X 20 |
| 3820 | 250000958 | Panel Nut M5 X 0.8 |
| 0383331 | 0383331 | INSTRUMENTS & CABLE ASSEMBLY |
