05- Suspension - Front
Parts (32)
| Ref | Part Number | Description |
|---|---|---|
| 15 | 706204637 | LH Lower Suspension Arm This part replaces 706203228. |
| 17 | 706204638 | RH Lower Suspension Arm This part replaces 706203229. |
| 20a | Not | Available As Spare Part - Coussinet |
| 20b | Not | Available As Spare Part - Douille |
| 20c | Not | Available As Spare Part - Plaque d'usure |
| 50 | 207607046 | Hex. Flange Screw M10 X 70 |
| 55 | 706202045 | Ball Joint |
| 56 | 706202044 | Ball Joint |
| 60 | 233201436 | Hex. Flange Elastic Nut M10 |
| 65 | 706200998 | Front Suspension Cross Plate |
| 70 | 706204572 | RH Upper Suspension Arm This part replaces 706204445. |
| 80 | 408200700 | Grease Fitting |
| 85 | 293550056 | Grease Fitting 90° |
| 100 | 706204571 | LH Upper Suspension Arm This part replaces 706204444. |
| 190 | 233261494 | Hex. Flange Elastic Nut M6 |
| 195 | 234062670 | Stainless Steel Flat Washer |
| 230 | 293370035 | Circlip |
| 236 | 705203247 | Upper Front Holder |
| 240 | 250100099 | Nut M12 |
| 241 | 706200281 | Hardened Washer This part replaces 250200086. |
| 242 | 207606044 | Hex. Flange Screw M10 X 60 |
| 243 | 233201434 | Hex. Flange Elastic Nut M10 |
| 250 | 211400017 | Cotter Pin |
| 280 | 207682534 | Hex. Flange Screw M8 X 25 |
| 290 | 233281414 | Hex. Flange Elastic Nut M8 |
| 300 | 706203715 | Sway Bar |
| 310 | 706203929 | Clamp |
| 320 | 706204796 | Stabilizer Bar Bushing This part replaces 706203286. |
| 330 | 207562054 | Hex. Flange Screw S.Grip M6 X 20 |
| 340 | 706203290 | LH Sway Bar Link |
| 350 | 706203291 | RH Sway Bar Link |
| 355 | 233201414 | Hex. Flange Elastic Nut M10 |
