| Ref | Part Number | Description |
|---|
| 1 |
219704453 |
Was 293550004 Dielectric Grease, 150 g |
| 2 |
414227300 |
Clip |
| 3 |
414115200 |
Tie-Rap 180 mm |
| 3 |
515175220 |
Wrap_Tie 200 X 4.6 - Call Your Local BRP Dealership |
| 4 |
219704354 |
Trim 1000Mm Long |
| 5 |
293750009 |
Tie-Rap 173 mm |
| 6 |
710001452 |
WIRE BRACKET - Call your local BRP dealership |
| 7 |
XXX |
Not Available As Spare Parts |
| 8 |
710002197 |
UNLOCKING CLIP - Call your local BRP dealership |
| 9 |
293150230 |
Tuflok Plastic Rivet This part replaces 293150089. |
| 10 |
270000141 |
Clip |
| 11 |
390402400 |
Pop Rivet 3/16" |
| 13 |
Not |
Available As Spare Part - Fixing Screw Kit |
| 14 |
Not |
Available As Spare Part - Fixing Nut Kit |
| 15 |
Not |
Available As Spare Part - Beam Harness |
| 16 |
219800100 |
Anti-Vibration Bushing |
| 17 |
219800099 |
Spacer |
| 18 |
219800101 |
Rubber Vent This part replaces 219800133. |
| 21 |
219800140 |
Halogen Bulb H9 65W |
| 22 |
219800174 |
Cover With Seal |
| 23 |
219800111 |
Adjustement Cable |
| 24 |
219800110 |
CHROMED SCREW 4X13 - Call your local BRP dealership |
| 25 |
Not |
Available As Spare Part - Module |
| 26 |
219800174 |
Cover With Seal This part replaces 219800139. |
| 27a |
710000779 |
Housing |
| 27b |
710004906 |
Connector Plug This part replaces 710002160. |
| 29 |
Not |
Available As Spare Part - Adaptor |
| 30 |
Not |
Available As Spare Part - Fixing Screw Kit |
| 31 |
Not |
Available As Spare Part - Fixing Nut Kit |
| 32 |
Not |
Available As Spare Part - Beam Harness |
| 33 |
219800100 |
Anti-Vibration Bushing |
| 34 |
219800099 |
Spacer |
| 35 |
219800101 |
Rubber Vent |
| 36 |
415129249 |
Halogen Bulb |
| 37 |
219800174 |
Cover With Seal |
| 38 |
219800105 |
Adjustement Cable |
| 39 |
219800110 |
CHROMED SCREW 4X13 - Call your local BRP dealership |
| 40 |
232170411 |
Hex. Jam Nut M14 |
| 41 |
207563034 |
Hex. Flange Screw M6 X 30, Scotch Grip |
| 42 |
250100198 |
Panel Nut M6 X 1.0 This part replaces 250100113. |
| 43 |
517302785 |
Edge Clip |
| 44 |
269500725 |
M6 Nut Housing Ass'y |
