| Ref | Part Number | Description |
|---|
| 9 |
207561244 |
Hex. Flange Screw M6 X 12, Scotch Grip |
| 10 |
207584034 |
Hex. Flange Screw, Scotch Grip |
| 11 |
207661644 |
Hex. Flange Screw M6 X 16 |
| 12 |
207662044 |
Hex. Flange Screw M6 X 20 |
| 13 |
207662544 |
Hex. Flange Screw M6 X 25 |
| 14 |
210261650 |
Hex. Flange Screw M6 X 16 This part replaces 210261680. |
| 15 |
210262040 |
Hex. Flange Screw M6 X 20 |
| 17 |
232561414 |
Elastic Stop Nut M6 |
| 18 |
233061414 |
Hex. Flange Nut M6 |
| 19 |
233261414 |
Hex. Flange Elastic Nut M6 x 1.0 |
| 20 |
233261416 |
Elastic Flange Nut M6 X 1.0 |
| 21 |
233281414 |
Hex. Flange Elastic Nut M8 |
| 22 |
234281474 |
Conical Spring Washer M8 |
| 23 |
250000958 |
Panel Nut M5 X 0.8 This part replaces 250000079. |
| 24 |
250000767 |
Torx Truss Screw M6 X 12 This part replaces 250000325. |
| 25 |
250000351 |
Hex. Flange Screw M8 X 25, Nylon |
| 26 |
250000779 |
Torx Screw M6 X 1.0 X 18, Scotch Grip This part replaces 250000402. |
| 27 |
250000534 |
Tork Screw M6 X 16 |
| 28 |
250000535 |
Torx Screw M8 X 55 |
| 29 |
250000536 |
Tork Screw M6 X 18 |
| 32 |
250200039 |
Flat Washer |
| 33 |
250300027 |
Clinch Stud M6 X 20 |
| 34 |
250300031 |
Clinch Stud M6 X 30 |
| 35 |
250300038 |
Clinch Stud |
| 38 |
293150104 |
Pop Rivet 3/16" |
| 39 |
293150108 |
Pop Rivet 3/16” This part replaces 293150108. |
| 41 |
293150119 |
Hemlock Rivet, 6.5 mm |
| 42 |
293150120 |
Hemlock Rivet 6.5 mm |
| 43 |
293150144 |
Stavex Rivet |
| 50 |
293150266 |
Ornit Rivet 6,5 X 14.5 This part replaces 293150147. |
| 55 |
293150146 |
Henrob Rivet |
| 60 |
293150174 |
Hemlock Rivet, 6.4 mm |
| 61 |
293150182 |
Monobolt Rivet 6.4 |
| 62 |
293150191 |
Monobolt Rivet, 4.8 mm |
| 70 |
293730041 |
Full Moon Dart 8 mm |
| 71 |
293730052 |
Black, Plug |
| 72 |
293730059 |
Full Moon Dart 10 mm |
| 77 |
XXX |
Not Available As Spare Parts |
| 87 |
293450275 |
Insert |
| 88 |
505073317 |
Leg Cushion |
| 90 |
512061516 |
Vibration Damper This part replaces 512060295. |
| 93 |
514054755 |
HEAT SHIELD - Call your local BRP dealership |
| 95 |
517124300 |
Washer |
| 99 |
XXX |
Not Available As Spare Parts |
| 101 |
518324874 |
RH Reinforcement |
| 102 |
518324875 |
LH Reinforcement |
| 103 |
XXX |
Not Available As Spare Parts |
| 104 |
XXX |
Not Available As Spare Parts |
| 109 |
XXX |
Not Available As Spare Parts |
| 111 |
518325377 |
RH ROLLER - Call your local BRP dealership |
| 111 |
518325378 |
LH Roller |
| 114 |
518325560 |
Adhesive Patch |
| 117 |
XXX |
Not Available As Spare Parts |
| 122 |
518325782 |
RH Deflector, Black Polypropylene |
| 124 |
518325783 |
LH Deflector, Black Polypropylene |
| 127 |
XXX |
Not Available As Spare Parts |
| 128 |
XXX |
Not Available As Spare Parts |
| 130 |
518325973 |
RH Rear Base |
| 130 |
518325974 |
LH Rear Base |
| 137 |
518328789 |
RH Bracket This part replaces 518326050. |
| 138 |
518328790 |
LH Bracket This part replaces 518326051. |
| 139 |
XXX |
Not Available As Spare Parts |
| 143 |
518326178 |
Engine Support |
| 145 |
518326198 |
Front Member |
| 146 |
518326328 |
RH Side Member |
| 147 |
518326330 |
LH Side Member |
| 148 |
518326355 |
Center Column Support |
| 151 |
518326472 |
Battery Support |
| 153 |
518326482 |
RH Support |
| 156 |
518326550 |
Retaining Plate |
| 158 |
518326559 |
Rear Member |
| 162 |
518326656 |
Seal |
| 166 |
518326641 |
Rear Radiator Ass'y, 137" |
| 175 |
518326820 |
LH Stirup |
| 177 |
518326848 |
Upper Column Support |
| 178 |
518326960 |
Support |
| 179 |
518326961 |
U-Attach |
| 181 |
518326970 |
Front Member |
| 182 |
518326973 |
Front Tunnel Protector |
| 184 |
518326986 |
Attach |
| 187 |
518327105 |
Rear Cap |
| 199 |
518327487 |
Front Suspension Support This part replaces 518327475. |
| 200 |
415130014 |
ASS'Y BRACE KIT - Call your local BRP dealership This part replaces 518327535. |
| 206 |
518328078 |
E Module |
| 209 |
415129827 |
FRAME RENEGADE LFF - Call your local BRP dealership |
| 211 |
518328320 |
Cross Member S Module This part replaces 518327721. |
| 216 |
XXX |
Not Available As Spare Parts |
| 217 |
XXX |
Not Available As Spare Parts |
