| Ref | Part Number | Description |
|---|
| 1 |
0587485 |
STARTER MOTOR |
| 2 |
0358912 |
BRACKET, Starter motor |
| 5 |
0355427 |
GROMMET, Starter mounting |
| 7 |
0356534 |
SCREW, Battery ground to starter motor |
| 9 |
0356466 |
NUT, M8x1.25 - Starter cable to solenoid |
| 10 |
0354321 |
BOOT, Starter cable |
| 12 |
0356234 |
NUT, M5 - Cable to starter solenoid |
| 15 |
5011559 |
FLYWHEEL ASSEMBLY This part replaces 5008961. |
| 19 |
0587245 |
STATOR AY,SWITCHER |
| 24 |
0320107 |
ATTACHE-CÂBLE, connecteur capteur de position de vilebrequin vers clapet |
| 27 |
0343525 |
SCREW, Stator |
| 33 |
0358436 |
BRACKET, Ignition coil mounting |
| 39 |
5009781 |
SPARK PLUG LEAD |
| 41 |
0587205 |
BATTERY CABLE, 10 ft. (3.0 m) |
| 41 |
0587301 |
BATTERY CABLE, 15 ft. (4.5 m) |
| 41 |
0587302 |
BATTERY CABLE, 20 ft. (6.0 m) |
| 46 |
0320107 |
ATTACHE-CÂBLE, connecteur capteur de position de vilebrequin vers clapet |
| 49 |
0320107 |
ATTACHE-CÂBLE, connecteur capteur de position de vilebrequin vers clapet |
